Ulefone Armor Pad Pro Rugged Tablets
8GB+128GB, 7650 mAh, 8-inch, Android 13, MediaTek MT8788, Network: 4G, NFC
Ulefone Armor Pad Pro features MediaTek MT8788, 8GB+128GB memory and storage, 8‑inch, 7650 mAh battery, Android 13. Military-Grade Durability: Engineered with MIL-STD-810H and IP68/IP69K certifications, this rugged chassis survives 1.5-meter drops and extreme environments for unrivaled reliability in the field. High-Efficiency Performance: The MediaTek MT8788 Octa-core processor paired with up to 16GB RAM（8GB of RAM + 8GB Virtual RAM） and 128GB expandable storage ensures high-speed multitasking and a clean Android 13 professional interface.
48MP Main Camera
Supports 18W charging
8‑inch
8GB+128GB physical memory and storage
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
Ulefone Armor Pad Pro Features
Ulefone Armor Pad Pro features MediaTek MT8788, 8GB+128GB memory and storage, 8‑inch, 7650 mAh battery, Android 13.
Military-Grade Durability
Engineered with MIL-STD-810H and IP68/IP69K certifications, this rugged chassis survives 1.5-meter drops and extreme environments for unrivaled reliability in the field.
High-Efficiency Performance
The MediaTek MT8788 Octa-core processor paired with up to 16GB RAM（8GB of RAM + 8GB Virtual RAM） and 128GB expandable storage ensures high-speed multitasking and a clean Android 13 professional interface.
Advanced Imaging System
A 48MP Samsung ISOCELL GM2 main sensor and 32MP front camera deliver high-resolution documentation and crystal-clear video conferencing for remote site inspections.
High-Capacity Battery
The 7,650mAh power cell provides up to 14 hours of continuous operation, supporting intensive GPS tracking and team communication throughout extended work shifts.
Triple Slot Connectivity
Integrated dual Nano SIM slots and a dedicated TF card tray enable global 4G LTE connectivity and massive data storage for uninterrupted mobile workflows.
Immersive 8.0″ Display
The reinforced 8.0-inch touchscreen and dual-speaker system provide a high-durability interface for precise outdoor data visualization and immersive audio feedback.
NFC Technology
Integrated NFC with Google Pay support facilitates swift, secure digital transactions and efficient mobile access control for professional transportation and logistics services.
uSmart Expansion Port
The exclusive uSmart connector enables plug-and-play integration with professional-grade endoscopes and microscopes for high-quality diagnostic imaging and technical analysis.
Size and Weight
Height: 213 mm. Width: 128.8 mm. Depth: 14.0 mm. Weight: 560 grams.
Charging and battery
7650 mAh. Built-in lithium-ion polymer battery. USB Type-C. Supports 18W charging. Battery Life. Standby Time | 414 Hours. Talk Time | 41 Hours.
Rugged
Splash, Water and Dust Resistant. Rated IP68 (maximum depth of 1.5 metres up to 30 minutes) under IEC standard 60529. Rated IP69K under IEC standard 60529. MIL-STD-810H Certification.
Display
8‑inch. All-screen LCD Multi-Touch display with IPS technology. Resolution: 800 x 1280 HD+.
Ulefone Armor Pad Pro Wholesale and Bulk Orders
Review the detailed technical specifications and product photographs before selecting this model for your order. Ulefone Armor Pad Pro offers 8GB+128GB memory and storage. View the colour finishes and device angles in the gallery. Accessories shown in feature illustrations are optional unless listed in the package contents. Contact RuggedMaster to discuss wholesale quantities and the configuration required for your order.
Explore the Ulefone Armor 27T Pro+ rugged phone and review the official Ulefone Armor Pad Pro specifications.
Ulefone Armor Pad Pro Manufacturer Notes
- The battery is non-removable, removing it may cause damage to the device.
- Product size and weight may vary by configuration, manufacturing process and measurements. All specifications are subject to the actual product.
- Power consumption data are from Ulefone lab, which will be varied by actual usage.
- Armor Pad Pro is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of
- 5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor Pad Pro. Liquid damage not covered under warranty.
- Armor Pad Pro has waterproof plugs for its charging port and audio jack, please tightly put the plugs into the holes before you put an Armor Pad Pro into water.
- The Custom Key and its ability to quickly access different functions work only when the screen is unlocked.
- The actual available RAM and storage are less than the listed total capacity due to the occupied storage of the operating system and software pre-installed in the device.
- The micro SD card is not included, and need to be purchased separately. The maximum 8GB of virtual RAM can be activated in Settings at your will.
- 8.0 inches is the diagonal length of the display when the four rounded corners are taken to be pointed corners, the actual viewable area is slightly smaller.
- The resolution is measured as a standard rectangle with a rounded corners design, the effective pixels are slightly less.
- The camera software functions are subject to the actual presence, some of functions and names may vary depending on the software version.
- The actual photo and video resolution may vary depending on the shooting mode.
- NFC and Google Pay is supported, and you are suggested to download Google Pay to use it; the available countries and regions are for your reference: https://pay.google.com/about.
- Due to the difference in material and thickness, some leather gloves may be incompatible.
- The product, accessories, and package may vary in different markets. Pictures are for reference only. Please refer to the actual products.
- The uSmart accessories mentioned above require additional purchases if needed.
- The Tablet Hand Strap with Kickstand requires an additional purchase if needed. Notes:
- The battery is non-removable, removing it may cause damage to the device.
- Product size and weight may vary by configuration, manufacturing process and measurements. All specifications are subject to the actual product.
- Power consumption data are from Ulefone lab, which will be varied by actual usage.
- Armor Pad Pro is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of
- 5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor Pad Pro. Liquid damage not covered under warranty.
- Armor Pad Pro has waterproof plugs for its charging port and audio jack, please tightly put the plugs into the holes before you put an Armor Pad Pro into water.
- The Custom Key and its ability to quickly access different functions work only when the screen is unlocked.
- The actual available RAM and storage are less than the listed total capacity due to the occupied storage of the operating system and software pre-installed in the device.
- The micro SD card is not included, and need to be purchased separately. The maximum 8GB of virtual RAM can be activated in Settings at your will.
- 8.0 inches is the diagonal length of the display when the four rounded corners are taken to be pointed corners, the actual viewable area is slightly smaller.
- The resolution is measured as a standard rectangle with a rounded corners design, the effective pixels are slightly less.
- The camera software functions are subject to the actual presence, some of functions and names may vary depending on the software version.
- The actual photo and video resolution may vary depending on the shooting mode.
- NFC and Google Pay is supported, and you are suggested to download Google Pay to use it; the available countries and regions are for your reference: https://pay.google.com/about.
- Due to the difference in material and thickness, some leather gloves may be incompatible.
- The product, accessories, and package may vary in different markets. Pictures are for reference only. Please refer to the actual products.
- The uSmart accessories mentioned above require additional purchases if needed.
- The Tablet Hand Strap with Kickstand requires an additional purchase if needed.
Ulefone Armor Pad Pro Specifications
| Size and Weight | |
|---|---|
| Height | 213 mm |
| Width | 128.8 mm |
| Depth | 14.0 mm |
| Weight | 560 grams |
| *Size and weight vary by configuration and manufacturing process. Actual measurements between individual products may vary. All specifications are subject to the actual product. | |
| Charging and battery | |
| 7650 mAh | |
| Built-in lithium-ion polymer battery | |
| USB Type-C | |
| Supports 18W charging | |
| Battery Life | |
| Standby Time | 414 Hours |
| Talk Time | 41 Hours |
| *Typical value. Actual capacity may vary slightly. This capacity is the nominal battery capacity. The actual battery capacity for each individual product may be slightly above or below the nominal battery capacity. | |
| * Non-removable battery. Removing the battery may cause damage to the device. | |
| *Use with original charger and data cable, the max charging power can reach 18W. The actual charging power will intelligently change with different scenarios, please refer to the actual use. | |
| Rugged | |
| Splash, Water and Dust Resistant | |
| Rated IP68 (maximum depth of 1.5 metres up to 30 minutes) under IEC standard 60529 | |
| Rated IP69K under IEC standard 60529 | |
| MIL-STD-810H Certification | |
| *Armor Pad Pro is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of 1.5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor Pad Pro. Liquid damage not covered under warranty. | |
| Display | |
| 8‑inch | |
| All-screen LCD Multi-Touch display with IPS technology | |
| Resolution | 800 x 1280 HD+ |
| *With a rounded corners design on the display, the diagonal length of the screen is 8 inches when measured according to the standard rectangle (the actual viewable area is slightly smaller). | |
| *The resolution measured as a standard rectangle, with a rounded corners design, the effective pixels are slightly less. | |
| Processor | |
| MediaTek MT8788 | |
| CPU | MT8788 |
| CPU architecture | 8, 4 x Arm Cortex-A73 2.0GHz, 4 x Arm Cortex-A53, 2.0GHz |
| CPU frequency | 2.0GHz |
| GPU | Arm Mali-G72 MP3 |
| GPU frequency | up to 800MHz |
| Storage and RAM | |
| 8GB+128GB | |
| RAM | 8GB memory |
| Flash storage | 128GB storage |
| microSD memory card Up to 2TB | |
| *Available storage and RAM are less than the total memory due to storage of the operating system and software pre-installed in the device. | |
| *The Virtual Memory Expansion can be activated in Settings and adds up to 8GB of RAM. Some software may not be compatible with this feature. | |
| *microSD card needs to be purchased separately. Recommended to use Class 10 memory cards, other memory cards are not guaranteed to be fully compatible. | |
| Rear Camera | |
| 48MP Main Camera | |
| SAMSUNG GM2 sensor | |
| 82.4° FOV, ƒ/1.79 | |
| Photo resolution | up to 6000x8000 pixel |
| Video resolution | up to 1080P |
| Flash | |
| Rear camera photography features | |
| Normal Mode, Mono Mode, Beauty Mode, 48MP Mode, Portrait, Pro Mode, Night Mode, Scan | |
| Ai Scene Detection, Grid Line, Self Timer, Capture Mode, Scene Mode, Anti-shake, Geo-Tagging, ZSD, Sound Switch, Watermark, White Balance, ISO, Anti Flicker, Volume Keys, Long Press, Restore Defaults | |
| Rear camera video features | |
| 1080P recording | 30fps |
| 720P recording | 30fps |
| 480P recording | 30fps |
| CIF recording | 30fps |
| *The actual photo and video resolution may vary depending on the shooting mode. | |
| *The camera software functions are subject to actual presence, some functions and names may vary depending on the software version. | |
| Front Camera | |
| 32MP selfie camera | |
| SAMSUNG GD1 sensor, 0.8µm, 5P, 78.0° FOV, ƒ/2.2 | |
| Front camera photography features | |
| Normal Mode, Mono Mode, Beauty Mode | |
| Grid line, Scene Mode, EIS, Geo-Tagging, Microphone, Sound Switch, Mirror Switch, White Balance, Anti Flicker, Volume Keys, Restore Defaults | |
| Front camera video features | |
| 1080P recording | 30fps |
| 720P recording | 30fps |
| 480P recording | 30fps |
| *In different photo modes, the number of pixels may be slightly different, please refer to the actual situation. | |
| *The actual photo and video resolution may vary depending on the shooting mode. | |
| *The camera software functions are subject to actual presence, some functions and names may vary depending on the software version. | |
| Audio | |
| Dual-Speaker Sound System | |
| Stereo sound | |
| 1216 Box *2 | |
| Unlock Options | |
| Supports Fingerprint Unlock | |
| Side-Mounted Fingerprint, Integrate power key and fingerprint sensor together | |
| Capacitive Touch Sensor | |
| Response speed | Up to 0.1s |
| Supports the enrollment of 5 sets of fingerprint | |
| Supports Face Unlock | |
| Network | |
| Supports use of dual SIM cards from different carriers | |
| Both cards can access 4G/3G connectivity simultaneously | |
| Dual Nano SIM; either card can be set as the primary card | |
| Supports 4G/3G/2G | |
| Supports VoLTE HD calling | |
| Supported network bands | |
| 4G Network | |
| 4G | FDD-LTE: B1/2/3/4/5/7/8/12/17/1920/28A/28B |
| TDD-LTE | B38/B40/B41 |
| 3G Network | |
| WCDMA | B1/2/4/5/8 |
| 2G Network | |
| GSM | B2/3/5/8 |
| *Dual 4G requires the support of local carriers services, and may not be available in all regions. | |
| *Only supports single SIM for communication service, which means when one of the SIM cards is in calling, the other SIM card will not be able to connect. | |
| *Only certain regions and telecom operators support VoLTE. | |
| Connectivity | |
| WLAN | |
| Supports protocols | 802.11 a/b/g/n/ac |
| Supports 2.4G/5G | |
| Bluetooth | |
| Supports Bluetooth 4.2 | |
| Navigation and positioning | |
| Supports multiple positioning systems | |
| GPS GLONASS Galileo Digital Compass | |
| uSmart Expansion | |
| uSmart E01 Endoscope | |
| uSmart E02 Endoscope uSmart C01 Supermicroscope | |
| *For more devices that are compatible with uSmart Expansion Connector, you are recommended to refer to our accessories list. Expansion devices require additional purchases. | |
| NFC | |
| Supports Google Pay | |
| Supports Transit, Loyalty Cards, Gift Cards and Plane tickets | |
| *Supported by Google Pay, you should download Google Pay to use it. Google Pay available countries and regions please refer to https://pay.google.com/about. | |
| Operating System | |
| Android 13 | |
| Pure Android System | |
| No ads | |
| Buttons | |
| Sensors | |
| NFC, Proximity sensor, Light sensor, Gravity sensor, Acceleration sensor, Geomagnetic sensor, Gyro sensor, Pedometer | |
| Multimedia | |
| Video | MOV/MKV/3GP/MP4 |
| Audio | MID/FLAC/MKA/MP3/M4A/AACAMR/OGG/MP2 |
| Image | GIF/JPEG/PNG/BMP |
| Ebook | TXT/HTML |
| Ports | |
| USB 2.0, Type-C | |
| 3.5 mm Headphone Jack uSmart Expansion Connector | |
| Card slot | |
| Three(3), Nano SIM + Nano SIM + microSD | |
| Notification Light | |
| Support, tri-color light, red/green/blue | |
| Supports charging prompt | |
| Language support | |
| Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese | |
| In the box | |
| 1 x Ulefone Armor Pad Pro | |
| 1 x AC Power Charger | |
| 1 x USB to Type-C Data Cable (100cm) | |
| 1 x Protective Film (Pre-installed) | |
| 1 x SIM Needle | |
| 1 x Lanyard | |
| 1 x Multi-language User Manual | |
| 1 x Multi-function Instruction Card | |
| 1 x Warranty Card | |
| 1 x Charging Instruction Card | |
| 1 x Safety Prompt Card | |
| 1 x Accessories Ecosystem Brochure | |
| 1 x Service Center APP Instructions | |
| *The AC power charger's plug type varies according to your region, with optional standard EU/AU/US plugs available. | |
| *May vary in different market. Subject to the actual product. | |
| *The apperance of package and accessories may be different, but the function remain the same, please refer to the actual. | |
| Specifications | |
| The tablet pictures and screen content on the above are for illustration only. The actual tablet (including but not limited to appearance, color, size) and screen (including but not limited to background, UI, and graphics) may be slightly different. Please refer to the actual product. | |
| The data on the page are theoretical values from Ulefone lab based on specific test environment (see details at specific description). In actual use, there may be slight differences due to product differences, software versions, use conditions and environmental factors, so please refer to actual situation as final. | |
| The preceding specifications are theoretical values based on product design. Some features and specifications may vary across markets. To provide accurate product information, specifications, and features, Ulefone may make real-time adjustments to the preceding specifications, so that they match the product performance, specifications, indexes, and components of the actual product. Product information is subject to such changes and adjustments without notice. | |
| The Android® word mark and logos are registered trademarks owned by Google. | |
| The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. | |
| USB-Type C™ and USB-C™ are trademarks of USB Implementers Forum. | |
One-stop Solutation
RUGGEDMASTER offer End-to-End Solutions from Design to Production
Rich Experience
RUGGEDMASTER has more than 10 years of OEM and ODM manufacturing experience in customizing rugged tablets,rugged phones,rugged handhelds,rugged laptop,etc.
Strong R & D Capabilities
More than 10 years experienced R&D engineers provide mature custom solutions of outdoors products
Strict Quality Control
Including raw material test, online production test, PCS test, finished product test.
Competitive prices
RUGGEDMASTER offer competitive prices as we are able to produce our products efficiently and cost-effectively in our own factory.
view more >
Just Email Us :
Email : sales@ruggedmaster.com
Address: 4th Floor, A3 Building Yinlong Industry Base, Longdong Community, Longgang District,Shenzhen
Between 9:00 am-6: 00 pm from Monday to Friday Beijing time
We will reply you witin 12hours.
Can I buy from you online directly?
No, direct online purchase is not acceptable now as we want to give our partner more profits at their side
Can you send me a price list or no middleman quotation?
Yes,we can send it to your directly,please just email us and get our latest quotation directly.
Can you send me a catalog or brochure?
Yes,You can email us and we will send you our latest products catalogs to you
Do Your Company Accept Customizaion?
Yes,We accept OEM service. We have our own factory and excellent RD team, OEM is a part of our business, in addition, we offer ODM service, we would love to make good ideas happen.
What's the normaly lead time for OEM order?
Takes about 30 days for 500pcs OEM order after sample confirmed.
Do you sell refurbished or reconditioned devices?
Hello, no, we do not supply any refurbished or reconditioned devices or produucts, if you are interested in our night vision products, you can send your dealer or distributor request information
Do you sell your products to the military?
no, we do not supply the military because our products do not meet military standards and are intended only for civil purposes such as hunting, security, monitoring and other civil fields.
For the civil interest, the customers can send the dealer or distributor request information
0
Years Of Successful Business
0
Reviews Of 10000+ Satisfied Clients
0
Years Factory Warranty
0
Patents owned in global
0
Business Partners
0
Risk-Free Guarantee
NEED BULK ORDER ?
