RUGGEDMASTER W86H Rugged Tablets
8-nch Anti-Scratched IPS Touch Screen, IP67 Waterproof, 4 GB RAM + 64 GB eMMC, 2MP Front camera + 5MP Back Camera, Built-in NXP NFC, Support GPS/GLONASS/QZSS, Support 4G FDD-LTE, 8,500mAh Battery
RUGGEDMASTER W86H combines 8-nch Anti-Scratched IPS Touch Screen, IP67 Waterproof, 4 GB RAM + 64 GB eMMC. Additional features include 2MP Front camera + 5MP Back Camera, Built-in NXP NFC, Support GPS/GLONASS/QZSS. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
8-nch Anti-Scratched IPS Touch Screen
IP67 Waterproof
4 GB RAM + 64 GB eMMC
2MP Front camera + 5MP Back Camera
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER W86H Rugged Tablets
RUGGEDMASTER W86H combines 8-nch Anti-Scratched IPS Touch Screen, IP67 Waterproof, 4 GB RAM + 64 GB eMMC. Additional features include 2MP Front camera + 5MP Back Camera, Built-in NXP NFC, Support GPS/GLONASS/QZSS. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER W86H features
RUGGEDMASTER W86H 8-Inch Touch Screen Waterproof Rugged Windows 10 Tablet PC with SIM Card
【RELIABILITY】Ruggedized design and IP67 waterproof / dust-proof housing, ideal for harsh industrial environment. It can withstand moisture, extreme temperatures, drops, shocks, vibration, rain, dirt, mud, sand, water, altitude, humidity.
【SUPERIOR HARDWARE SOLUTIONS FOR ENTERPRISE MOBILITY】 Powerful CPU: Intel Cherrytrail Z8350, 1.44Ghz~1.92Ghz + Intel HD Graphics GPU, allows for high speed running of multiple tasks. Windows 10 Home or Android 5.1 operating system. 4 GB DDR3L RAM, 64 GB eMMC ROM, support SDHC/SDXC card up to 128 GB max. 8-inch 16:10 anti-scratched IPS capacitive touch screen, 800*1280px, 320 nits, support handwriting. Front camera: 2.0MP with indicator light, back camera 5.0MP.
【OUTSTANDING BATTERY DURABILITY】Built-in 3.7V/8,500mAh Li-Po battery, it allows a full day of fieldwork, without worrying about data loss in the field. An essential production tool to get jobs done, ideal for enterprise mobile solutions.
【MULTIPLE DATA CAPTURING AND NETWORK CONNECTIVITY】BT Version 4.0. Wi-Fi IEEE 802.11 a/b/g/n/c, support dual-band Wi-Fi (2.4GHz+5GHz). Built-in U-Blox NEO-7 module, support GPS/GLONASS/QZSS
Design and technical configuration
The RUGGEDMASTER W86H technical information lists the following configuration details.
Operating system: Windows 10 Home or Android 5.1 (Windows 10 Pro is optional). Dimension: 228*145*16.5 mm. Net weight: 630g. Gross weight: 1,330g (Unit with gift box and standard accessories), docking: 290g.
Colour: Bottom shell: silver, front shell: black; all black is optional. Display: 8-inch anti-scratched IPS capacitive touch screen, 800*1280px, 320 nits, support handwriting. Processor: Intel Cherrytrail Z8350, 1.44Ghz~1.92Ghz; GPU: Intel® HD Graphics. RAM: 4 GB DDR3L.
ROM: 64 GB eMMC, support SDHC/SDXC card up to 128 GB maximally. Camera: Front camera: 2.0MP with indicator light, rear camera: 5.0MP. Battery: Built-in 3.7V/8,500mAh Li-Po battery (If using 4G configuration, battery capacity is 7,800mAh). Sensor: Gravity sensor.
Speaker: Embedded 8 Ω/0.8W waterproof speaker * 1. Mic: Sensitivity: -42db, output resistance 2.2 kΩ. Bands: 2G: GSM 850/900/1800/1900 MHz. Bands: 3G: WCDMA 850/900/1900/2100MHz.
RUGGEDMASTER W86H wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER W86H. Browse our rugged tablets to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details. The original product information provides the technical reference.
RUGGEDMASTER W86H specifications
| RUGGEDMASTER W86H technical specifications | |
|---|---|
| Model No. | RUGGEDMASTER W86H |
| Operating system | Windows 10 Home or Android 5.1 (Windows 10 Pro is optional) |
| Dimension | 228*145*16.5 mm |
| Net weight | 630g |
| Gross weight | 1,330g (Unit with gift box and standard accessories), docking: 290g |
| Colour | Bottom shell: silver, front shell: black; all black is optional |
| Language | Multi-language |
| Display | 8-inch anti-scratched IPS capacitive touch screen, 800*1280px, 320 nits, support handwriting |
| Processor | Intel Cherrytrail Z8350, 1.44Ghz~1.92Ghz; GPU: Intel® HD Graphics |
| RAM | 4 GB DDR3L |
| ROM | 64 GB eMMC, support SDHC/SDXC card up to 128 GB maximally |
| Camera | Front camera: 2.0MP with indicator light, rear camera: 5.0MP |
| Battery | Built-in 3.7V/8,500mAh Li-Po battery (If using 4G configuration, battery capacity is 7,800mAh) |
| Sensor | Gravity sensor |
| Speaker | Embedded 8 Ω/0.8W waterproof speaker * 1 |
| Mic | Sensitivity: -42db, output resistance 2.2 kΩ |
| Bands | 2G: GSM 850/900/1800/1900 MHz |
| Bands | 3G: WCDMA 850/900/1900/2100MHz |
| Bands | 4G: FDD-LTE B1/B2/B3/B4/B5/B7/B8/B20 |
| Wi-Fi | IEEE 802.11 a/b/g/n/c, support 2.4GHz/5GHz dual-band Wi-Fi |
| BT | V4.0 (BLE) class1.5 transmission distance: 10 m |
| NFC | NXP NFC, Card reading distance: 4 cm |
| GNSS | Built-in U-Blox NEO-7 module, support GPS/GLONASS/QZSS |
| TF card slot | *1 |
| ∮3.5 mm earphone port | *1 |
| 12-pin Pogo Pin | *1 |
| USB 2.0 port | *1 |
| HD-MI port | V1.4a Type C *1 |
| DC jack | 5V/3A ∮3.5 mm Power connector *1 |
| Waterproof | IP67 |
| Drop-proof | MIL-STD-810G, 1.2 m, composite wood floors, in operation status |
| Temperature range | Operating: -10 °C~50 °C (-20 °C~60 °C is optional;) Storage: -30 °C~70 °C |
| Humidity | 95% Non-Condensing |
| 1D scanning Module | MOTO SE655E100R |
| 2D scanning Module | MOTO SE4710 Hardware decoder |
| OTG cable | *1 |
| USB cable | *1 |
| Power adaptor | *1 (5V/3A) |
| Charger docking | Optional |
