RUGGEDMASTER T80E Rugged Tablets
8.68 inch TFT, 800 x 1340, 400 nits10-point capacitive touchscreen, support Glove&Water · 8000mAh/3.85V/ Built-in Polymer Lithium-ion Battery / Approximately 11h13min · MT8781 · Android 14/GMS · 8GB LPDDR4x on board128GB UFS2.2 Optional 256GB UFS2.2 · -30℃ to 70℃ · Bluetooth® V5.1
Hot sale & Classical Low cost Rugged Tablet Full-Features to Deliver the Best Service T80E rugged tablet with barcode scanner supports Android 14 with GMS, Rugged IP65 protective grade for waterproof & dustproof. Intel core with Android 14/Gorilla glass TP, easy to operate. Support 1D/2D, NFC, and other functional modules for free selection. Integrated 3G/4G all network communication, 1D/2D barcode scanner/USB/NFC /WiFi,/Bluetooth, and other communication modes.T80E built in removeable 8000mAh battery, 10 hours of machine endurance.
Dimension: 220.14*135.5*14mm
Weight: 569g
Display / Touch Panel: 8.68 inch TFT, 800 x 1340, 400 nits10-point capacitive touchscreen, support Glove&Water
Battery: 8000mAh/3.85V/ Built-in Polymer Lithium-ion Battery / Approximately 11h13min
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER T80E Rugged Tablets
RUGGEDMASTER T80E combines the features and configurations shown below. Review the product overview, original feature graphics and complete Specs when selecting units for a bulk order.
Hot sale & Classical Low cost Rugged Tablet
Full-Features to Deliver the Best Service
T80E rugged tablet with barcode scanner supports Android 14 with GMS, Rugged IP65 protective grade for waterproof & dustproof. Intel core with Android 14/Gorilla glass TP, easy to operate. Support 1D/2D, NFC, and other functional modules for free selection. Integrated 3G/4G all network communication, 1D/2D barcode scanner/USB/NFC /WiFi,/Bluetooth, and other communication modes.T80E built in removeable 8000mAh battery, 10 hours of machine endurance.
Configuration overview
Technical specifications include Dimension: 220.14*135.5*14mm. Weight: 569g. Display / Touch Panel: 8.68 inch TFT, 800 x 1340, 400 nits10-point capacitive touchscreen, support Glove&Water. Battery: 8000mAh/3.85V/ Built-in Polymer Lithium-ion Battery / Approximately 11h13min.
Technical specifications include Power Adapter: PD Fast Charge Adapter +Type-C Data Cable（1m）33W PD：5V~20V/0~1.5AOptional:(EU, US, UK, AU) Choose one of four. Speaker: Integrated 2W speaker x2. I/O Interfaces: USB 2.0×1、Type C×1、SIM Card x1,TF Cardx1 Max 512GB, 12pins Pogo Pin x1,φ3.5mm standard earphone jack ×1, φ3.5mm DCjack×1. Buttons: Power button, volume+- button..
Technical specifications include Camera: Front 5.0MP With working indicatorRear 13.0MP，autofocus with flash. CPU: MT8781 (6x 2.2Ghz Cortex-A76, 2x 2.0Ghz Cortex-A55). Operating System: Android 14/GMS. Storage: 8GB LPDDR4x on board128GB UFS2.2 Optional 256GB UFS2.2.
Technical specifications include Operating Temp.: -20℃ to 60℃. Storage Temp.: -30℃ to 70℃. Humidity: 95%（Non-Condensing）. Drop Specifications: 1.22m drop resistance.
Technical specifications include IP Protective Level: IP68 certified, MIL-STD-810H certified. SDK: Dingdata Software Development Kit. Language: Java. Environment: Android Studio or Eclipse.
Technical specifications include WWAN: Integrated 4G LTE multi-carrier mobile broadbandLTE-FDD(B1/2/3/4/5/7/8/12/17/18/19/20//25/26/28A/28B/66)LTE-TDD(B34/38/39/40/41)WCDMA(B1/2/4/5/8)GSM(B2/3/5/8). WIFI: Intel® Wi-Fi 5（802.11 ac）. Bluetooth: Bluetooth® V5.1. GPS: Integrated GPS,Beidou,Galileo,Glonass module.
Wholesale purchasing information
For RUGGEDMASTER T80E, compare the pictured housing, connectors and controls with the configuration required by your application. The manufacturer may describe optional modules, memory configurations or regional network bands. These options are listed for reference; confirm the required configuration when requesting a quotation. Choose the interface and data-capture functions that match your existing workflow, software and installation requirements.
Review the complete Specs tab before placing a bulk order. It preserves the technical information supplied for this model, including the available operating environment and configuration details. Product pictures show the manufacturer’s existing views and available configurations. If your project needs a particular module, operating system version or connector, state that requirement in your enquiry so the configuration can be checked before ordering.
Explore related products in our RuggedMaster product catalog or send a bulk-order enquiry.
Manufacturer feature details
| SPECIFICATIONS | ||
| PHYSICAL CHARACTERISTICS | ||
| Dimension | 220.14*135.5*14mm | |
| Weight | 569g | |
| Display / Touch Panel | 8.68 inch TFT, 800 x 1340, 400 nits10-point capacitive touchscreen, support Glove&Water | |
| Battery | 8000mAh/3.85V/ Built-in Polymer Lithium-ion Battery / Approximately 11h13min | |
| Power Adapter | PD Fast Charge Adapter +Type-C Data Cable（1m）33W PD：5V~20V/0~1.5AOptional:(EU, US, UK, AU) Choose one of four | |
| Speaker | Integrated 2W speaker x2 | |
| I/O Interfaces | USB 2.0×1、Type C×1、SIM Card x1,TF Cardx1 Max 512GB, 12pins Pogo Pin x1,φ3.5mm standard earphone jack ×1, φ3.5mm DCjack×1 | |
| Buttons | Power button, volume+- button. | |
| Camera | Front 5.0MP With working indicatorRear 13.0MP，autofocus with flash | |
| PERFORMANCE CHARACTERSTICS | ||
| CPU | MT8781 (6x 2.2Ghz Cortex-A76, 2x 2.0Ghz Cortex-A55) | |
| Operating System | Android 14/GMS | |
| Storage | 8GB LPDDR4x on board128GB UFS2.2 Optional 256GB UFS2.2 | |
| USER ENVIRONMENT | ||
| Operating Temp. | -20℃ to 60℃ | |
| Storage Temp. | -30℃ to 70℃ | |
| Humidity | 95%（Non-Condensing） | |
| Drop Specifications | 1.22m drop resistance | |
| IP Protective Level | IP68 certified, MIL-STD-810H certified | |
| DEVELOPMENT ENVIRONMENT | ||
| SDK | Dingdata Software Development Kit | |
| Language | Java | |
| Environment | Android Studio or Eclipse | |
| DATA COMMUNICATION | ||
| WWAN | Integrated 4G LTE multi-carrier mobile broadbandLTE-FDD(B1/2/3/4/5/7/8/12/17/18/19/20//25/26/28A/28B/66)LTE-TDD(B34/38/39/40/41)WCDMA(B1/2/4/5/8)GSM(B2/3/5/8) | |
| WIFI | Intel® Wi-Fi 5（802.11 ac） | |
| Bluetooth | Bluetooth® V5.1 | |
| GPS | Integrated GPS,Beidou,Galileo,Glonass module | |
| DATA CAPTUER | ||
| Support face unlocking | ||
| RFID HF/ NFC | NFC 13.56MHz Supports 14443A/14443B/15693 of ISO/IEC, Reading Distance: 0 to 4cm | |
| ACCESSORIES | ||
| Standard | 1xStandard Adaptor | |
| Optional | Docking Charger, Spare Battery，TP protective film | |
