RUGGEDMASTER ST11-A3 Rugged Tablets
OS: Android 9.0 (support Google play) or Android 11.0 (support GMS), CPU: MTK P60 MT6771 Octa A73 core 2.0 GHz, RAM/ROM: 8GB/128GB OR 6GB/128GB, OR 4GB/64GB, LCD: 10.1 inch1920*1200； | 500 nits sunshine readable, Touch screen: 10 point touch, support stylus, Power and battery: battery total capacity 10500mAh | 8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap, Power and battery: 3.5*1.35mm, 5V 3A DC in put | Magnetic charger, GPS: baidou,GPS, glonass
RUGGEDMASTER ST11-A3 combines OS: Android 9.0 (support Google play) or Android 11.0 (support GMS), CPU: MTK P60 MT6771 Octa A73 core 2.0 GHz, RAM/ROM: 8GB/128GB OR 6GB/128GB, OR 4GB/64GB. Additional features include LCD: 10.1 inch1920*1200； | 500 nits sunshine readable, Touch screen: 10 point touch, support stylus, Power and battery: battery total capacity 10500mAh | 8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
OS: Android 9.0 (support Google play) or Android 11.0 (support GMS)
CPU: MTK P60 MT6771 Octa A73 core 2.0 GHz
RAM/ROM: 8GB/128GB OR 6GB/128GB, OR 4GB/64GB
LCD: 10.1 inch1920*1200； | 500 nits sunshine readable
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER ST11-A3 Rugged Tablets
RUGGEDMASTER ST11-A3 combines OS: Android 9.0 (support Google play) or Android 11.0 (support GMS), CPU: MTK P60 MT6771 Octa A73 core 2.0 GHz, RAM/ROM: 8GB/128GB OR 6GB/128GB, OR 4GB/64GB. Additional features include LCD: 10.1 inch1920*1200； | 500 nits sunshine readable, Touch screen: 10 point touch, support stylus, Power and battery: battery total capacity 10500mAh | 8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER ST11-A3 features
Product Introduction
Design and technical configuration
The RUGGEDMASTER ST11-A3 technical information lists the following configuration details.
OS: Android 9.0 (support Google play) or Android 11.0 (support GMS). CPU: MTK P60 MT6771 Octa A73 core 2.0 GHz. RAM/ROM: 8GB/128GB OR 6GB/128GB, OR 4GB/64GB. LCD: 10.1 inch1920*1200； | 500 nits sunshine readable.
Touch screen: 10 point touch, support stylus. Camera: 5M/13M, flash. Power and battery: battery total capacity 10500mAh | 8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap. Power and battery: 3.5*1.35mm, 5V 3A DC in put | Magnetic charger.
WWAN: 4G LTE, 3G WCDMA, GSM | 4G Fre: FDD: B1,B2, B3,B5, B7, B8, B12， B20 TDD: B38,B39,B40,B41 B34 WCDMA:B1, B8 TD-SCDMA: B34, B39 GSM/GPRS/EDGE. GPS: baidou,GPS, glonass. wifi: 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G. BLUETOOTH: 4.0 version.
NFC: 13.56 MHz, distance 5cm or above. SPEAKER: 1.5 watt. Sensor: 1. light sensor 2. compass 3. gravity 4. acceleration 5. baroceptor. size: 275*178*18mm.
Multi-media (Hardware decoding): Photo Viewer | BMP, JPG, GIF, PNG. Multi-media (Hardware decoding): Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P). Multi-media (Hardware decoding): Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license). interface in/out port: 1. normal USB*1 2. Micro USB*1 3. RJ45*1 4. bottom pogopin*1, USB and serial 5. back pogopin*1 6. DC*1 3.5*1.35 7. microphone+earphone 8. RS232*1.
Pogopin definition: 1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V OUT) 2. 8pin in bottom； （1USB, 1 RS232， 1 UART， ) VESA hole 75*75mm or 90*90mm. casing material: ABS/PC. button: V+ -, Power, P, F, H. 2D barcode module: honeywell N3680 | optional.
RUGGEDMASTER ST11-A3 wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER ST11-A3. Browse our rugged tablets to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
RUGGEDMASTER ST11-A3 Rugged Tablets specifications
| RUGGEDMASTER ST11-A3 Rugged Tablets technical specifications | |||
|---|---|---|---|
| OS | Android 9.0 (support Google play) or Android 11.0 (support GMS) | ||
| CPU | MTK P60 MT6771 Octa A73 core 2.0 GHz | ||
| RAM/ROM | 8GB/128GB OR 6GB/128GB, OR 4GB/64GB | ||
| LCD | 10.1 inch1920*1200； | 500 nits sunshine readable | |
| Touch screen | 10 point touch, support stylus | ||
| Camera | 5M/13M, flash | 5M/13M, flash | |
| Power and battery | battery total capacity 10500mAh |
8400mAh,hotswap, 2100mAh backup power 3.8V 3A imput, support hotswap |
|
| 3.5*1.35mm, 5V 3A DC in put | Magnetic charger | ||
| WWAN | 4G LTE, 3G WCDMA, GSM |
4G Fre: FDD: B1,B2, B3,B5, B7, B8, B12， B20 TDD: B38,B39,B40,B41 B34 WCDMA:B1, B8 TD-SCDMA: B34, B39 GSM/GPRS/EDGE |
|
| GPS | baidou,GPS, glonass | ||
| wifi | 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G | ||
| BLUETOOTH | 4.0 version | ||
| NFC | 13.56 MHz, distance 5cm or above | ||
| SPEAKER | 1.5 watt | ||
| Sensor |
1. light sensor 2. compass 3. gravity 4. acceleration 5. baroceptor |
||
| size | 275*178*18mm | ||
|
Multi-media (Hardware decoding) |
Photo Viewer | BMP, JPG, GIF, PNG | |
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) | ||
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | ||
| language | multi language | ||
|
interface in/out port |
1. normal USB*1 2. Micro USB*1 3. RJ45*1 4. bottom pogopin*1, USB and serial 5. back pogopin*1 6. DC*1 3.5*1.35 7. microphone+earphone 8. RS232*1 |
||
| Pogopin definition |
1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V OUT) 2. 8pin in bottom； （1USB, 1 RS232， 1 UART， ) VESA hole 75*75mm or 90*90mm |
||
| casing material | ABS/PC | ||
| button | V+ -, Power, P, F, H | ||
| 2D barcode module | honeywell N3680 | optional | |
| UHF | reading and write distance 1meter to 10 meter | optional | |
| fingerprint module | LD-8800-M | optional | |
|
standard accessories in gift box |
1. USB cable 2. charger( 4-in-1) 3. handstrap 4. handstring 5. white box, no logo |
||
|
optional accessories |
1. car docking 2. extra battery 3. screen protective film 4. car holder 5. docking station 6. car charger |
||
| proof rate |
1. water proof IP65 2. Drapping proof 1.2 meter |
||
| Certification |
1. 810G 2. CE,FCC |
||
| Temperature |
1. storate temperature -25 to 80 degree 2. operation temperature -20 to 60 degree |
||
