RUGGEDMASTER SPA141 combines Screen: screen | 14 inch FULL HD IPS screen, Screen: Resolution | 1920×1080, Screen: Brightness | 300 cdm2. Additional features include Screen: contrast | 1000:1, Screen: Display area | 16：9/ Display area : 309×174mm. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.

RUGGEDMASTER SPA141 features

Product Introduction

Design and technical configuration

The RUGGEDMASTER SPA141 technical information lists the following configuration details.

Screen: screen | 14 inch FULL HD IPS screen. Screen: Resolution | 1920×1080. Screen: Brightness | 300 cdm2. Screen: contrast | 1000:1.

Screen: Display area | 16：9/ Display area : 309×174mm. configuration: CPU | Allwinner A83T eight core processor, clocked 2.0G. configuration: Ram | 2GB. configuration: ROM | 16GB.

configuration: OS | Android 7.0. Network: WIFI | 802.11b/g/n. Network: Ethernet | Supports connection to the RJ45 network interface. Network: Bluetooth | Bluetooth 3.0.

Network: 3G/4G | Support external 3G/4G USB dongle. Interface: SD | 1×SD card slots (max support 32GB). Interface: Mini USB | 1×USB OTG (through it to debug the machine, brush the system program). Interface: USB | 3×USB 2.0 interface (support U disk, mouse, keyboard, printer etc).

Interface: RJ45 | 1×RJ45 network interface. Interface: earphone | 1×3.5mm headphone jack. Interface: Power | 1×4.0mm power DC jack. Media plays: video | Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P).

Media plays: Audio | Support MP3, WMA, AAC and so on. Media plays: picture | JPEG、JPG. Others: Wireless mouse keyboard | support. Others: speaker | 2×2W speakers.

Configuration and compatibility

Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.

Preparing a deployment enquiry

To compare this industrial panel pcs configuration with your existing equipment, start with the tasks your team performs and the software it uses. Check the operating system and application requirements against the listed processor, memory and storage. For connected workflows, compare the specified communication methods and interfaces with your network and peripherals. If scanning or identification is part of the job, identify the barcode types or card standards required before choosing optional hardware. Review the source photos alongside the dimensions to assess handling, mounting and access to connections. Include these requirements with your requested quantity so the proposed configuration can be checked before supply. Listed options need confirmation; the gallery may illustrate several configurations.

RUGGEDMASTER SPA141 wholesale enquiries

Explore the product photos and the separate Specs tab for RUGGEDMASTER SPA141. Browse our industrial panel pcs to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
