RUGGEDMASTER S16TWP Rugged Tablets
Type: FHD Size: 10.1 inch 16:10Resolution: 1200*1920Brightness: 400nit10 point capacitive touch screen · 5000mAh/7.4V / Removable Li-polyment Battery / 6.5 hours · Intel® Celeron® Processor N5100 · Windows 11 Pro(Optional:Home/IOT) · RAM 8GB DDR + ROM 128GB SSD removable · -30℃ to 70℃ · BT5.1 Transmission distance: 10m
10.1 inch Intel Windows Rugged Tablet PC Full-Features to Deliver the Best Service S16TWP support for Windows 11 Pro system, it built-in 5000mAh/7.6V pluggable battery, 10 hours of machine endurance. It up to IP65 high protection level, in accordance with MIL-STD-810G. At the same time, support GPS, Glonass, more accurate positioning and 1D/2D, NFC, ID card and other functional modules for free selection. Support aviation plug to meet the requirements of industrial electricity. Integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes.
Dimension: 280.4*187*26.6 mm
Weight: 1014g
Display / Touch Panel: Type: FHD Size: 10.1 inch 16:10Resolution: 1200*1920Brightness: 400nit10 point capacitive touch screen
Battery: 5000mAh/7.4V / Removable Li-polyment Battery / 6.5 hours
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER S16TWP Rugged Tablets
RUGGEDMASTER S16TWP combines the features and configurations shown below. Review the product overview, original feature graphics and complete Specs when selecting units for a bulk order.
10.1 inch Intel Windows Rugged Tablet PC
Full-Features to Deliver the Best Service
S16TWP support for Windows 11 Pro system, it built-in 5000mAh/7.6V pluggable battery, 10 hours of machine endurance. It up to IP65 high protection level, in accordance with MIL-STD-810G. At the same time, support GPS, Glonass, more accurate positioning and 1D/2D, NFC, ID card and other functional modules for free selection. Support aviation plug to meet the requirements of industrial electricity. Integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes.
Configuration overview
Technical specifications include Dimension: 280.4*187*26.6 mm. Weight: 1014g. Display / Touch Panel: Type: FHD Size: 10.1 inch 16:10Resolution: 1200*1920Brightness: 400nit10 point capacitive touch screen. Battery: 5000mAh/7.4V / Removable Li-polyment Battery / 6.5 hours.
Technical specifications include Power Adapter: AC100V ~ 240V, 50Hz/60Hz, DC 12V/4AOptional:(EU, US, UK, AU) Choose one of four. Speaker: 8Ω/1W Waterproof BOX Speaker *1. I/O Interfaces: HDMI 2.0a Mini x 1, USB Type-C x 1, USB 3.0 Type-A x 1, SIM Card x 1, TF Card x 1,12PIN Pogo Pin x 1, DB9 RS232 x 1, RJ45 x 1, Φ3.5mm standard earphone jack x 1,DC 12V 4A ∮4.0mm jack *1. Buttons: Power *1Volume Adjustment Key (+) *1Volume Adjustment Key (-) *1F Key *1 (Barcode Scanning), When there is no scanning function, it can be customizedP Key *1 (HOME Key), When there is no scanning function, it can be customized.
Technical specifications include Camera: Front 5.0MP (MIPI) Rear 8.0MP (MIPI). CPU: Intel® Celeron® Processor N5100. Operating System: Windows 11 Pro(Optional:Home/IOT). Storage: RAM 8GB DDR + ROM 128GB SSD removable.
Technical specifications include Operating Temp.: -20℃ to 60℃. Storage Temp.: -30℃ to 70℃. Humidity: 95%, no condensation. Drop Specifications: 1.22m drop resistance.
Technical specifications include IP Protective Level: IP65 certified, MIL-STD-810G certified. WWAN: MeiG 750 VELTE-FDD: B1/3/5/7/8/20LTE-TDD: B40WCDMA: B1/5/8GSM: 900/1800China (Unicom, mobile support is poor, only B8 supports without TDD band) Europe, Middle East, Africa, Taiwan, JapanOptional, South America or North America module. WIFI: Wi-Fi 802.11 a/b/g/n/ac (2.4G+5.8G). Bluetooth: BT5.1 Transmission distance: 10m.
Technical specifications include GPS: Support GPS, Glonass. Barcode Scanning (optional): Honeywell N4680Optical resolution: 5milScanning speed: 50 times /sSupport code: PDF417, MicroPDF417, Data Matrix, Data Matrix InverseMaxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse. RFID HF/ NFC (optional): NXP300NXP NFC 13.56MHz supports 14,443A/14,443B/15,693/18,092/mobile protocol under ISO/IEC. Card reading distance: 4cm. Fingerprint scanner: Fingerprint(optional).
Wholesale purchasing information
For RUGGEDMASTER S16TWP, compare the pictured housing, connectors and controls with the configuration required by your application. The manufacturer may describe optional modules, memory configurations or regional network bands. These options are listed for reference; confirm the required configuration when requesting a quotation. Choose the interface and data-capture functions that match your existing workflow, software and installation requirements.
Review the complete Specs tab before placing a bulk order. It preserves the technical information supplied for this model, including the available operating environment and configuration details. Product pictures show the manufacturer’s existing views and available configurations. If your project needs a particular module, operating system version or connector, state that requirement in your enquiry so the configuration can be checked before ordering.
Explore related products in our RuggedMaster product catalog or send a bulk-order enquiry.
Manufacturer feature details
| SPECIFICATIONS | ||
| PHYSICAL CHARACTERISTICS | ||
| Dimension | 280.4*187*26.6 mm | |
| Weight | 1014g | |
| Display / Touch Panel | Type: FHD Size: 10.1 inch 16:10Resolution: 1200*1920Brightness: 400nit10 point capacitive touch screen | |
| Battery | 5000mAh/7.4V / Removable Li-polyment Battery / 6.5 hours | |
| Power Adapter | AC100V ~ 240V, 50Hz/60Hz, DC 12V/4AOptional:(EU, US, UK, AU) Choose one of four | |
| Speaker | 8Ω/1W Waterproof BOX Speaker *1 | |
| I/O Interfaces | HDMI 2.0a Mini x 1, USB Type-C x 1, USB 3.0 Type-A x 1, SIM Card x 1, TF Card x 1,12PIN Pogo Pin x 1, DB9 RS232 x 1, RJ45 x 1, Φ3.5mm standard earphone jack x 1,DC 12V 4A ∮4.0mm jack *1 | |
| Buttons | Power *1Volume Adjustment Key (+) *1Volume Adjustment Key (-) *1F Key *1 (Barcode Scanning), When there is no scanning function, it can be customizedP Key *1 (HOME Key), When there is no scanning function, it can be customized | |
| Camera | Front 5.0MP (MIPI) Rear 8.0MP (MIPI) | |
| PERFORMANCE CHARACTERSTICS | ||
| CPU | Intel® Celeron® Processor N5100 | |
| Operating System | Windows 11 Pro(Optional:Home/IOT) | |
| Storage | RAM 8GB DDR + ROM 128GB SSD removable | |
| USER ENVIRONMENT | ||
| Operating Temp. | -20℃ to 60℃ | |
| Storage Temp. | -30℃ to 70℃ | |
| Humidity | 95%, no condensation | |
| Drop Specifications | 1.22m drop resistance | |
| IP Protective Level | IP65 certified, MIL-STD-810G certified | |
| DATA COMMUNICATION | ||
| WWAN | MeiG 750 VELTE-FDD: B1/3/5/7/8/20LTE-TDD: B40WCDMA: B1/5/8GSM: 900/1800China (Unicom, mobile support is poor, only B8 supports without TDD band) Europe, Middle East, Africa, Taiwan, JapanOptional, South America or North America module | |
| WIFI | Wi-Fi 802.11 a/b/g/n/ac (2.4G+5.8G) | |
| Bluetooth | BT5.1 Transmission distance: 10m | |
| GPS | Support GPS, Glonass | |
| DATA CAPTUER | ||
| Barcode Scanning (optional) | Honeywell N4680Optical resolution: 5milScanning speed: 50 times /sSupport code: PDF417, MicroPDF417, Data Matrix, Data Matrix InverseMaxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse | |
| RFID HF/ NFC (optional) | NXP300NXP NFC 13.56MHz supports 14,443A/14,443B/15,693/18,092/mobile protocol under ISO/IEC. Card reading distance: 4cm | |
| Fingerprint scanner | Fingerprint(optional) | |
| ACCESSORIES | ||
| Standard | 1xHand Straps，1xStandard Adaptor，1xCarry Handle strap，1xOTG Cable | |
| Optional | Hand writing pen，Shoulder girdle，Car charger，Vehicle bracket holder M16，Docking Charger，Back Straps，Spare Replace Battery，Leather case | |
