RUGGEDMASTER S10A Rugged Tablets
10.1 inch; 1200*1920; 450nits, 10 Point Touch,Support stylusOptional: 1000nits display(1200*1920) · Main battery: 12000mAh / voltage 3.8Vdc (45.6Wh)Secondary battery: 2400mAh, Supports hot-swapping · MT6877, Octa Core; 2.4GHz · Android 15.0 · 8GB/256GB, (Optional 16GB/512GB ) · -25℃ to 80℃ · 5.2 Version, backward compatible
10.1 inch Android Rugged Tablet Full-Features to Deliver the Best Service S10A support for Android 13 system, integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes, it supplort 12000mAh +2400mAh double battery and 10 hours of machine endurance, IP67 high protection level, in accordance with MIL-STD-810G, optional GPS, more accurate positioning. Support 13 million pixel auto focus camera, easy to collect images and video information. Support 1D/2D,NFC ,RFID UHF and other functional modules for free selection.
Dimension: 273*172*20mm
Weight: 1080±50g
Display / Touch Panel: 10.1 inch; 1200*1920; 450nits, 10 Point Touch,Support stylusOptional: 1000nits display(1200*1920)
Battery: Main battery: 12000mAh / voltage 3.8Vdc (45.6Wh)Secondary battery: 2400mAh, Supports hot-swapping
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER S10A Rugged Tablets
RUGGEDMASTER S10A combines the features and configurations shown below. Review the product overview, original feature graphics and complete Specs when selecting units for a bulk order.
10.1 inch Android Rugged Tablet
Full-Features to Deliver the Best Service
S10A support for Android 13 system, integrated 3G/4G all network communication, WiFi, Bluetooth and other communication modes, it supplort 12000mAh +2400mAh double battery and 10 hours of machine endurance, IP67 high protection level, in accordance with MIL-STD-810G, optional GPS, more accurate positioning. Support 13 million pixel auto focus camera, easy to collect images and video information. Support 1D/2D,NFC ,RFID UHF and other functional modules for free selection.
Configuration overview
Technical specifications include Dimension: 273*172*20mm. Weight: 1080±50g. Display / Touch Panel: 10.1 inch; 1200*1920; 450nits, 10 Point Touch,Support stylusOptional: 1000nits display(1200*1920). Battery: Main battery: 12000mAh / voltage 3.8Vdc (45.6Wh)Secondary battery: 2400mAh, Supports hot-swapping.
Technical specifications include Power Adapter: DC 5V 3A ∮3.5mmOptional:(EU, US, UK, AU) Choose one of four. Speaker: 8Ω 1.5 Watt. I/O Interfaces: Type-C *1; OTGSIM Card Slot*1，TF Card Slot*1Earphone*1DC*1; 3.5*12mm，USB 2.0 *1RJ45*1，RS232*1Bottom pogopin: USB 2.0; Charging; RS232Back pogopin: USB 2.0; RS232EDP interface Optional，Reserved interface. Buttons: V+ -, Power, "F" for Barcode Scan Customized Button: P,H.
Technical specifications include Camera: Front: 8MP; Real: 16MP, Flash light. Multi-Media(Hardware Decoding): 1. Photo Viewer: BMP, JPG, GIF, PNG2. Video Format: MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license). CPU: MT6877, Octa Core; 2.4GHz. Operating System: Android 15.0.
Technical specifications include Storage: 8GB/256GB, (Optional 16GB/512GB ). Operating Temp.: -20℃ to 55℃. Storage Temp.: -25℃ to 80℃. Humidity: Relative Humidity (93±3)% RH.
Technical specifications include Drop Specifications: Dropping Resistance 1.2 meters. IP Protective Level: Anti-dust & Waterproof IP65-IP67 , MIL-STD-810G, ISO, MSDS，CE, FCC, 3C. SDK: Dingdata Software Development Kit. Language: Java.
Technical specifications include Environment: Android Studio or Eclipse. WWAN: 5G：N1/N5/N8/N28AB/N78/N41FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28TDD_LTE: B34/B38/B39/B40/B41/B66WCDMA: 850/900/1900/2100CDMA2000: BC0TD-SCDMA: B34/B39GSM: 850/900/1800/1900. WIFI: 802.11a/b/g/n/ac/ax Wireless Internet Wireless AP( Mobile AP )2.4G, 5G; support Wifi 6. Bluetooth: 5.2 Version, backward compatible.
Wholesale purchasing information
For RUGGEDMASTER S10A, compare the pictured housing, connectors and controls with the configuration required by your application. The manufacturer may describe optional modules, memory configurations or regional network bands. These options are listed for reference; confirm the required configuration when requesting a quotation. Choose the interface and data-capture functions that match your existing workflow, software and installation requirements.
Review the complete Specs tab before placing a bulk order. It preserves the technical information supplied for this model, including the available operating environment and configuration details. Product pictures show the manufacturer’s existing views and available configurations. If your project needs a particular module, operating system version or connector, state that requirement in your enquiry so the configuration can be checked before ordering.
Explore related products in our RuggedMaster product catalog or send a bulk-order enquiry.
Manufacturer feature details
| SPECIFICATIONS | ||
| PHYSICAL CHARACTERISTICS | ||
| Dimension | 273*172*20mm | |
| Weight | 1080±50g | |
| Display / Touch Panel | 10.1 inch; 1200*1920; 450nits, 10 Point Touch,Support stylusOptional: 1000nits display(1200*1920) | |
| Battery | Main battery: 12000mAh / voltage 3.8Vdc (45.6Wh)Secondary battery: 2400mAh, Supports hot-swapping | |
| Power Adapter | DC 5V 3A ∮3.5mmOptional:(EU, US, UK, AU) Choose one of four | |
| Speaker | 8Ω 1.5 Watt | |
| I/O Interfaces | Type-C *1; OTGSIM Card Slot*1，TF Card Slot*1Earphone*1DC*1; 3.5*12mm，USB 2.0 *1RJ45*1，RS232*1Bottom pogopin: USB 2.0; Charging; RS232Back pogopin: USB 2.0; RS232EDP interface Optional，Reserved interface | |
| Buttons | V+ -, Power, "F" for Barcode Scan Customized Button: P,H | |
| Camera | Front: 8MP; Real: 16MP, Flash light | |
| Multi-Media(Hardware Decoding) | 1. Photo Viewer: BMP, JPG, GIF, PNG2. Video Format: MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P)3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) | |
| PERFORMANCE CHARACTERSTICS | ||
| CPU | MT6877, Octa Core; 2.4GHz | |
| Operating System | Android 15.0 | |
| Storage | 8GB/256GB, (Optional 16GB/512GB ) | |
| USER ENVIRONMENT | ||
| Operating Temp. | -20℃ to 55℃ | |
| Storage Temp. | -25℃ to 80℃ | |
| Humidity | Relative Humidity (93±3)% RH | |
| Drop Specifications | Dropping Resistance 1.2 meters | |
| IP Protective Level | Anti-dust & Waterproof IP65-IP67 , MIL-STD-810G, ISO, MSDS，CE, FCC, 3C | |
| DEVELOPMENT ENVIRONMENT | ||
| SDK | Dingdata Software Development Kit | |
| Language | Java | |
| Environment | Android Studio or Eclipse | |
| DATA COMMUNICATION | ||
| WWAN | 5G：N1/N5/N8/N28AB/N78/N41FDD_LTE: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28TDD_LTE: B34/B38/B39/B40/B41/B66WCDMA: 850/900/1900/2100CDMA2000: BC0TD-SCDMA: B34/B39GSM: 850/900/1800/1900 | |
| WIFI | 802.11a/b/g/n/ac/ax Wireless Internet Wireless AP( Mobile AP )2.4G, 5G; support Wifi 6 | |
| Bluetooth | 5.2 Version, backward compatible | |
| GPS | BDS, GPS, GLONASS | |
| DATA CAPTUER | ||
| Barcode Scanning (optional) | Honeywell N4680Optical resolution: 5milScanning speed: 30 times /sSupport code: PDF417, MicroPDF417, Data Matrix, Data Matrix InverseMaxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse" | |
| RFID HF（NFC） | 13.56 MHz, Distance: 1-3cm | |
| High Precision GPS(optional) | UM960 Module | |
| Fingerprint (optional) | AFM60 Module (Support RTK) | |
| UHF RFID (optional) | M-500American standard M-500 (902Mhz – 928Mhz)External: card reading distance of 3-5MEuropean standard M-500 (865MHz – 868MHz)External: Card reading distance of 3-5MM-301American standard M-301 (902Mhz – 928Mhz)External: card reading distance of 5-8MEuropean standard M-301 (865MHz – 868MHz)External: Card reading distance of 5-8M | |
| ACCESSORIES | ||
| Standard | 1xCarry Handle strap; 1xStandard Adaptor,1xWrist strap | |
| Optional | Car Charger , Car Docking Charger Mount , Car Holder Mount , Docking Charger,Extra spare Battery , Hand writing pen, Active stylus, Removable keyboard. | |
