RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs

RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs

RUGGEDMASTER catalog model: RM-SC-C763AD8C55E1.

RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs combines Operating System: Windows 11 Home Edition/Professional version/Enterprise Edition | Windows 10 Optional, CPU: Support Intel i3、i5、i7 | Could choose disposition, RAM/ROM: RAM：8GB、16GB ROM: 128GB/256GB/512G（SSD） | Could choose disposition. Additional features include Display screen: 15.0-inch 1:1, Display type: TFT-LCD, Display Area: 304.128(H)×228.096(V)mm. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.

RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs features

Product Introduction

Design and technical configuration

The RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs technical information lists the following configuration details.

Items: Description | Remark. Operating System: Windows 11 Home Edition/Professional version/Enterprise Edition | Windows 10 Optional. CPU: Support Intel i3、i5、i7 | Could choose disposition. GPU: Intel i3、i5、i7,Dual-core、Quad-core、Octa-core.

RAM/ROM: RAM：8GB、16GB ROM: 128GB/256GB/512G（SSD） | Could choose disposition. Display screen: 15.0-inch 1:1. Display type: TFT-LCD. Resolution: 1024*768.

Display Area: 304.128(H)×228.096(V)mm. Viewing Angle: 89°/89°/89°/89°(CR>10)TYP. Display Color: 16.7M colors | 6-bit+FRC color depth. Touch: G+G 10 points of touch.

Mohs Hardness: 7H. Cooling Type: Fan Cooling. Dimension: 352.4*279.4*41mm. Weight: 3.75kg(Bare metal) | about4.35kg(Machine，includeData cable and charger）.

Material: LCD screen + glass panel + stainless steel body. Network Capabilities: 1* RTL8111H Gigabit LAN card, support Wake-on-LAN and PXE function. Audio Functions: On-board ALC897 7.1+2-channel hi-fi audio controller, support MIC/Line-out. Horn: Standard no horns | Optional 8 euros 5W horn Stereo.

Interfaces: 1. 1× DC_IN power supply interface 2. 1×HDMI Audio and video output 3. 2×USB3.0 4. 1×USB2.0 5. 1×LAN 6. 2×RS232. DC: Support 12V voltage，12V/4A. Wireless Network: wifi、bluetooth. Operating temperature: -20℃~55℃.

Configuration and compatibility

Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.

Preparing a deployment enquiry

To compare this industrial panel pcs configuration with your existing equipment, start with the tasks your team performs and the software it uses. Check the operating system and application requirements against the listed processor, memory and storage. For connected workflows, compare the specified communication methods and interfaces with your network and peripherals. If scanning or identification is part of the job, identify the barcode types or card standards required before choosing optional hardware. Review the source photos alongside the dimensions to assess handling, mounting and access to connections. Include these requirements with your requested quantity so the proposed configuration can be checked before supply. Listed options need confirmation; the gallery may illustrate several configurations.

RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs wholesale enquiries

Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-C763AD8C55E1 Industrial Panel PCs. Browse our industrial panel pcs to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
