RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals
OS: Android 13.0, CPU: Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) | 2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz, RAM/ROM: 4GB/64GB | 8GB/128GB Optional, LCD: 5.7 inch; 720*1520; 400nits, Touch Screen: 10 Point Touch | Support stylus, Power and Battery: 4000mAh; 3.8V (15.2Wh), GPS: BDS, GPS, GLONASS, BLUETOOTH: 5.0 Version
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals combines OS: Android 13.0, CPU: Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) | 2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz, RAM/ROM: 4GB/64GB | 8GB/128GB Optional. Additional features include LCD: 5.7 inch; 720*1520; 400nits, Touch Screen: 10 Point Touch | Support stylus, Power and Battery: 4000mAh; 3.8V (15.2Wh). The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
OS: Android 13.0
CPU: Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) | 2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz
RAM/ROM: 4GB/64GB | 8GB/128GB Optional
LCD: 5.7 inch; 720*1520; 400nits
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals
RUGGEDMASTER catalog model: RM-SC-C66563BE5868.
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals combines OS: Android 13.0, CPU: Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) | 2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz, RAM/ROM: 4GB/64GB | 8GB/128GB Optional. Additional features include LCD: 5.7 inch; 720*1520; 400nits, Touch Screen: 10 Point Touch | Support stylus, Power and Battery: 4000mAh; 3.8V (15.2Wh). The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals features
Product Introduction
Design and technical configuration
The RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals technical information lists the following configuration details.
OS: Android 13.0. CPU: Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) | 2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz. GPU: Mali-G57 MP1. RAM/ROM: 4GB/64GB | 8GB/128GB Optional.
LCD: 5.7 inch; 720*1520; 400nits. Touch Screen: 10 Point Touch | Support stylus. Camera: Front: 5MP; Rear: 13MP | Flash light. Power and Battery: 4000mAh; 3.8V (15.2Wh).
WWAN: 4G LTE,3G WCDMA,GSM | 4G Fre: FDD_LTE: B1/B2/B3/B5/B7/B8/B20 TDD_LTE：B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8. GPS: BDS, GPS, GLONASS. WIFI: 802.11a/b/g/n/ac Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G. BLUETOOTH: 5.0 Version.
SPEAKER: 8Ω 1.0 Watt. NFC: 13.56 MHz. Sensor: 1. Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Gyroscope. Size: 155*77.7*13.3mm.
Weight: 230±20g. Interface In/Out Port: 1. Type-C *1; OTG 2. SIM Card Slot*2 or SIM+TF Card Slot | Bottom pogopin*4. Button: V+ -, Power, SOS, Scan,Customized Button. 1D/2D Barcode: Optional | NLS-N1 Optional.
Accessories: 1. Box 2. Charger (5V 2A) 3. Ejection Pin. Multi-Media (Hardware Decoding): 1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license). Proof Degree: Anti-dust & Waterproof IP65 Dropping Resistance 1.5 meter. Certification: 1. MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C.
Configuration and compatibility
Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals. Browse our industrial handhelds to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals specifications
RUGGEDMASTER catalog model: RM-SC-C66563BE5868
| RUGGEDMASTER RM-SC-C66563BE5868 Handheld Terminals technical specifications | ||
|---|---|---|
| ITEM | DESCRIPTION | DETAIL |
| OS | Android 13.0 | |
| CPU |
Unisoc T7250 /T616/T606(Octa Core; 1.8GHz) |
2x Cortex-A75 @1.8GHz 6x Cortex-A55 @1.6GHz |
| GPU |
Mali-G57 MP1 |
|
| RAM/ROM | 4GB/64GB |
8GB/128GB Optional |
| LCD |
5.7 inch; 720*1520; 400nits |
|
| Touch Screen |
10 Point Touch |
Support stylus |
| Camera |
Front: 5MP; Rear: 13MP |
Flash light |
|
Power and Battery |
4000mAh; 3.8V (15.2Wh) |
|
| WWAN |
4G LTE,3G WCDMA,GSM |
4G Fre: FDD_LTE: B1/B2/B3/B5/B7/B8/B20 TDD_LTE：B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
| GPS |
BDS, GPS, GLONASS |
|
| WIFI |
802.11a/b/g/n/ac Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G |
|
| BLUETOOTH |
5.0 Version |
|
| SPEAKER |
8Ω 1.0 Watt |
|
| NFC |
13.56 MHz |
|
| Sensor |
1. Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Gyroscope |
|
| Size | 155*77.7*13.3mm | |
| Weight | 230±20g | |
| Language | Multi language | |
|
Interface In/Out Port |
1. Type-C *1; OTG 2. SIM Card Slot*2 or SIM+TF Card Slot |
Bottom pogopin*4 |
| Button |
V+ -, Power, SOS, Scan,Customized Button |
|
| 1D/2D Barcode | Optional |
NLS-N1 Optional |
| Accessories |
1. Box 2. Charger (5V 2A) 3. Ejection Pin |
|
|
Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree |
Anti-dust & Waterproof IP65 Dropping Resistance 1.5 meter |
|
| Certification |
1. MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature |
Storate Temperature: -40 °C to 60 °C Operation Temperature: -25 °C to 50 °C |
|
