Description
RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets
RUGGEDMASTER catalog model: RM-SC-C0F42D30E04E.
RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets combines DC4.0*1.7mm, 12V 3A DC in put, NFC 13.56 MHz, distance 5cm or above, language 语言 multi language. Additional features include button V+ -, Power, P, F, H. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets features
Product Introduction
DC4.0*1.7mm, 12V 3A DC in put
NFC 13.56 MHz, distance 5cm or above
weight 1.1kg
language 语言 multi language
button V+ -, Power, P, F, H
Design and technical configuration
The RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets technical information lists the following configuration details.
OS: windows 10 home/pro/iot. CPU: intel Jasper Lake, N4500(2 core)/N5100 (4 core) 1GHZ to 2.8GHz standard one is N5100. RAM/ROM: 8GB/256GB 4GB/64GB， 4GB/128GB optional. LCD: 10.1 inch1920*1200； max 500 nits sunshine readable.
Touch screen: 10 point touch support tylus support thin glove touch. Camera: 2M/5M， 5M/13M optional. Power and battery: 6000mAh, 7.6V lithium battery DC4.0*1.7mm, 12V 3A DC in put. WWAN: 4G LTE, 3G WCDMA, GSM, Quectel EC25AUGC “4G Fre: FDD: B1,B2, B3, B4, B5, B7, B8, B28 TDD: B40 B34 WCDMA:B1, B2,B4,B5,B8 GSM: B2, B3, B5, B8.
GPS: baidou,GPS, glonass. wifi: 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G intel 3165. BLUETOOTH: 4.2 version. NFC: 13.56 MHz, distance 5cm or above.
SPEAKER: 1.5 watt. Sensor: 1. light sensor 2. acceleration/gravity. size: 275*178*18mm. weight: 1.1kg Multi-media (Hardware decoding)” Photo Viewer BMP, JPG, GIF, PNG.
Video Format: MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P). Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license). Pogopin definition: 1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V) 2. 8pin in bottom； （1USB, 1 RS232， 1 UART， 5V) VESA hole 75*75mm or 90*90mm. casing material: ABS/PC/rubber TPU/aluminum.
button: V+ -, Power, P, F, H. 2D barcode module: honeywell N3680 optional. UHF: 900MHz optional. fingerprint: support optional.
Configuration and compatibility
Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.
RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets. Browse our rugged tablets to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets specifications
| RUGGEDMASTER catalog model | RM-SC-C0F42D30E04E |
|---|---|
| RUGGEDMASTER RM-SC-C0F42D30E04E Rugged Tablets technical specifications | |
| OS | windows 10 home/pro/iot |
| CPU | intel Jasper Lake, N4500(2 core)/N5100 (4 core) 1GHZ to 2.8GHz standard one is N5100 |
| RAM/ROM | 8GB/256GB 4GB/64GB， 4GB/128GB optional |
| LCD | 10.1 inch1920*1200； max 500 nits sunshine readable |
| Touch screen | 10 point touch support tylus support thin glove touch |
| Camera | 2M/5M， 5M/13M optional |
| Power and battery | 6000mAh, 7.6V lithium battery DC4.0*1.7mm, 12V 3A DC in put |
| WWAN | 4G LTE, 3G WCDMA, GSM, Quectel EC25AUGC "4G Fre: FDD: B1,B2, B3, B4, B5, B7, B8, B28 TDD: B40 B34 WCDMA:B1, B2,B4,B5,B8 GSM: B2, B3, B5, B8 |
| GPS | baidou,GPS, glonass |
| wifi | 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G intel 3165 |
| BLUETOOTH | 4.2 version |
| NFC | 13.56 MHz, distance 5cm or above |
| SPEAKER | 1.5 watt |
| Sensor | 1. light sensor 2. acceleration/gravity |
| size | 275*178*18mm |
| weight | 1.1kg Multi-media (Hardware decoding)" Photo Viewer BMP, JPG, GIF, PNG |
| Video Format | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) |
| Audio Format | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) |
| language | 语言 multi language interface in/out port" "1.USB 3.0 *2 2. RJ45*1 3. bottom pogopin*1, USB and serial 4. back pogopin*1 5. DC*1 3.5*1.35 6. microphone+earphone 7. HDMI 8.RS232*1 |
| Pogopin definition | 1.16pin back of cover, include （1USB, 1 RS232， 1 UART， 3.3V, 5V) 2. 8pin in bottom； （1USB, 1 RS232， 1 UART， 5V) VESA hole 75*75mm or 90*90mm |
| casing material | ABS/PC/rubber TPU/aluminum |
| button | V+ -, Power, P, F, H |
| 2D barcode module | honeywell N3680 optional |
| UHF | 900MHz optional |
| fingerprint | support optional |
| Front NFC | under the screen, the distance is 3-5cm, mifare one is optional optional |
| high precision GPS | 0.25-1 meter high precision GPS, support GPS, beidou, glonass optional |
| accessories | 1. USB cable 2. charger 3. handstrap 4. car holder 5. docking station 6. car charger 7. white box, no logo proof rate "1. water proof IP65 2. Drapping proof 1.2 meter |
| Certification | 1. 810G 2. CE,FCC |
| Temperature | 1. storate temperature -25 to 80 degree 2. operation temperature -20 to 60 degree |
