RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets
8 inch android 16 industrial rugged tablet, OS: Android 16.0, CPU: MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) | 2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz, RAM/ROM: 4GB/64GB， 6GB/128GB | 8GB/256GB, 12GB/256GB Optional, LCD: 8 inch; 1200*1920; IPS | 350nits (TYP) 390nits (MAX) (800*1280)1000nits Optional, Touch Screen: 10 Point Touch | Support stylus, Power and Battery: 7800mAh; 3.8V, GPS: BDS, GPS, GLONASS | WiFi/Bluetooth/GPS 3-in-1 (MT6631B)
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets combines 8 inch android 16 industrial rugged tablet, OS: Android 16.0, CPU: MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) | 2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz. Additional features include RAM/ROM: 4GB/64GB， 6GB/128GB | 8GB/256GB, 12GB/256GB Optional, LCD: 8 inch; 1200*1920; IPS | 350nits (TYP) 390nits (MAX) (800*1280)1000nits Optional, Touch Screen: 10 Point Touch | Support stylus. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
8 inch android 16 industrial rugged tablet
OS: Android 16.0
CPU: MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) | 2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz
RAM/ROM: 4GB/64GB， 6GB/128GB | 8GB/256GB, 12GB/256GB Optional
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets
RUGGEDMASTER catalog model: RM-SC-90B000FD16C3.
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets combines 8 inch android 16 industrial rugged tablet, OS: Android 16.0, CPU: MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) | 2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz. Additional features include RAM/ROM: 4GB/64GB， 6GB/128GB | 8GB/256GB, 12GB/256GB Optional, LCD: 8 inch; 1200*1920; IPS | 350nits (TYP) 390nits (MAX) (800*1280)1000nits Optional, Touch Screen: 10 Point Touch | Support stylus. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets features
Product Introduction
Design and technical configuration
The RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets technical information lists the following configuration details.
OS: Android 16.0. CPU: MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) | 2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz. GPU: Mali-G57 MC2. RAM/ROM: 4GB/64GB， 6GB/128GB | 8GB/256GB, 12GB/256GB Optional.
LCD: 8 inch; 1200*1920; IPS | 350nits (TYP) 390nits (MAX) (800*1280)1000nits Optional. Touch Screen: 10 Point Touch | Support stylus. Camera: Front: 5MP; Rear: 13MP | Flash light. Power and Battery: 7800mAh; 3.8V.
WWAN: 4G LTE,3G WCDMA,GSM | FDD-LTE: B1/B2/B3/B5/B7/B8/B12/B17/B20/B28 TDD-LTE: B34/B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8. GPS: BDS, GPS, GLONASS | WiFi/Bluetooth/GPS 3-in-1 (MT6631B). WIFI: 802.11a/b/g/n/ac Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G | WiFi/Bluetooth/GPS 3-in-1 (MT6631B). BLUETOOTH: 5.0 Version | WiFi/Bluetooth/GPS 3-in-1 (MT6631B).
NFC: 13.56 MHz, Distance: 1-3cm | ISO14443 TYPE A. MIC: Sensitivity: -32±2d Output Impedance: 2.2kΩx1. SPEAKER: 8Ω 1.5 Watt. Sensor: 1. Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Acceleration sensor 7. Gyroscope.
Size: 234*144*16.8mm. Weight: 630±20g. Interface In/Out Port: 1. Type-C *1; OTG 2. SIM Card Slot*1 3. TF Card Slot*1 4. Earphone*1 5. DC*1; 3.5*15mm 6. USB 2.0 *2 7. RS232*1(mini-USB) | Bottom pogopin: USB 2.0; Charging; RS232 Back pogopin: USB 2.0; RS232. Button: V+ -, Power, “F” for Barcode Scan | Customized Button: P,H (Default No Functionality).
1D/2D Barcode: Optional | NLS-N1 Optional M1 Optional SE2707 Optional. UHF RFID: Optional | American standard M500 (902Mhz – 928Mhz) External: card reading distance of 3-5M. UHF RFID: Optional | European standard M500 (865MHz – 868MHz) External: Card reading distance of 3-5M. Fingerprint: Optional | E064N Optional ZAZ-0A0 Optional 1020A Optional.
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets. Browse our rugged tablets to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets specifications
RUGGEDMASTER catalog model: RM-SC-90B000FD16C3
| RUGGEDMASTER RM-SC-90B000FD16C3 Rugged Tablets technical specifications | ||
|---|---|---|
| OS | Android 16.0 | |
| CPU |
MTK MT6789 (Octa Core, Octa Threads; 2.2GHz) |
2 × Arm Cortex-A76@2.2GHz 6 × Arm Cortex-A55@2.0GHz |
| GPU |
Mali-G57 MC2 |
|
| RAM/ROM |
4GB/64GB， 6GB/128GB |
8GB/256GB, 12GB/256GB Optional |
| LCD |
8 inch; 1200*1920; IPS |
350nits (TYP) 390nits (MAX) (800*1280)1000nits Optional |
| Touch Screen |
10 Point Touch |
Support stylus |
| Camera |
Front: 5MP; Rear: 13MP |
Flash light |
|
Power and Battery |
7800mAh; 3.8V | |
| WWAN |
4G LTE,3G WCDMA,GSM |
FDD-LTE: B1/B2/B3/B5/B7/B8/B12/B17/B20/B28 TDD-LTE: B34/B38/B39/B40/B41 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8 |
| GPS |
BDS, GPS, GLONASS |
WiFi/Bluetooth/GPS 3-in-1 (MT6631B) |
| WIFI |
802.11a/b/g/n/ac Wireless Internet Wireless AP ( Mobile AP )2.4G, 5G |
|
| BLUETOOTH |
5.0 Version |
|
| NFC |
13.56 MHz, Distance: 1-3cm |
ISO14443 TYPE A |
| MIC |
Sensitivity: -32±2d Output Impedance: 2.2kΩx1 |
|
| SPEAKER |
8Ω 1.5 Watt |
|
| Sensor |
1. Light sensor 2. Magnetic sensor 3. Pressure sensor 4. G-sensor 5. Distance sensor 6. Acceleration sensor 7. Gyroscope |
|
| Size | 234*144*16.8mm | |
| Weight | 630±20g | |
| Language | Multi language | |
|
Interface In/Out Port |
1. Type-C *1; OTG 2. SIM Card Slot*1 3. TF Card Slot*1 4. Earphone*1 5. DC*1; 3.5*15mm 6. USB 2.0 *2 7. RS232*1(mini-USB) |
Bottom pogopin: USB 2.0; Charging; RS232 Back pogopin: USB 2.0; RS232 |
| Button |
V+ -, Power, "F" for Barcode Scan |
Customized Button: P,H (Default No Functionality) |
| 1D/2D Barcode | Optional |
NLS-N1 Optional M1 Optional SE2707 Optional |
| UHF RFID | Optional |
American standard M500 (902Mhz – 928Mhz) External: card reading distance of 3-5M |
|
European standard M500 (865MHz – 868MHz) External: Card reading distance of 3-5M |
||
| Fingerprint | Optional |
E064N Optional ZAZ-0A0 Optional 1020A Optional |
| Accessories |
1. Blue Box 2. DC Charger (5V 3A) 3. Wrist strap 4. Screw |
Optional: 1. Docking Station 2. Car Holder 3. Car Docking |
|
Multi-Media (Hardware Decoding) |
1. Photo Viewer: BMP, JPG, GIF, PNG 2. Video Format: MEPG 1/2/4,H.263/H.264, RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) 3. Audio Format: MP3,WMA,WAV,OGG,FLAC,ALAC, APE,AAC,AC-3,DTS (need license) |
|
| Proof Degree |
Anti-dust & Waterproof IP65 Dropping Resistance 1.2 meters |
|
| Certification |
1. MIL-STD-810G 2. ISO-9001 3. CE, FCC, 3C |
|
| Temperature |
Storate Temperature: -25 °C to 80 °C Operation Temperature: -20 °C to 55 °C |
|
