RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs
Display Area: 307.5(W)×231(H)mm, Display Color: 16.2M colors, CPU: Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W, Memory: 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB, Memory: Function SSD, Operating System: WIN10/WIN 11 pre-installed (no activation code)
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs combines Display Area: 307.5(W)×231(H)mm, Display Color: 16.2M colors, CPU: Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W. Additional features include Memory: 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB, Memory: Function SSD, Operating System: WIN10/WIN 11 pre-installed (no activation code). The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
Display Area: 307.5(W)×231(H)mm
Display Color: 16.2M colors
CPU: Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W
Memory: 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs
RUGGEDMASTER catalog model: RM-SC-780F07257DEE.
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs combines Display Area: 307.5(W)×231(H)mm, Display Color: 16.2M colors, CPU: Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W. Additional features include Memory: 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB, Memory: Function SSD, Operating System: WIN10/WIN 11 pre-installed (no activation code). The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs features
Product Introduction
Network Functions 2* RTL8111H Gigabit LAN card, support Wake-on-LAN and PXE function. Audio Functions On-board ALC897 7.1+2-channel hi-fi audio controller, support MIC/Line-out. amplifier Support for audio input and output Interfaces 1× DC_IN power supply interface 1× HDMI 1×VGA 2× USB3.0,2X USB2.0 1× LAN interface 2xCOM 1× Mic (input) 1× PHONE (Output) 1× VGA DC 9-36V wide voltage Wireless Network wifi 2.4& 5G，bluetooth
Design and technical configuration
The RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs technical information lists the following configuration details.
Panel Size: 15-inch 4:3. Panel Type: TFT-LCD. Resolution: 1024*768. Display Area: 307.5(W)×231(H)mm.
Contrast: Ratio 1500:1. Viewing Angle: 89°/89°/89°/89° (Typ.)(CR≥10). Display Color: 16.2M colors. Touch: Type Capacitive 10-point touch.
Mohs Hardness: 7H. CPU: Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W. Cooling Type: Fanless Cooling. Memory: 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB.
Memory: Function SSD. Operating System: WIN10/WIN 11 pre-installed (no activation code). Dimension: 395*309.5*57.9mm. Material: LCD screen + glass panel + stainless steel body.
Network Functions: 2* RTL8111H Gigabit LAN card, support Wake-on-LAN and PXE function.. Audio Functions: On-board ALC897 7.1+2-channel hi-fi audio controller, support MIC/Line-out. amplifier Support for audio input and output. Interfaces: 1× DC_IN power supply interface 1× HDMI 1×VGA 2× USB3.0,2X USB2.0 1× LAN interface 2xCOM 1× Mic (input) 1× PHONE (Output) 1× VGA. DC: 9-36V wide voltage.
Wireless Network: wifi 2.4& 5G，bluetooth.
Configuration and compatibility
Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs wholesale enquiries
Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs. Browse our industrial panel pcs to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs specifications
| RUGGEDMASTER catalog model | RM-SC-780F07257DEE |
|---|---|
| RUGGEDMASTER RM-SC-780F07257DEE Industrial Panel PCs technical specifications | |
| Panel Size | 15-inch 4:3 |
| Panel Type | TFT-LCD |
| Resolution | 1024*768 |
| Display Area | 307.5(W)×231(H)mm |
| Contrast | Ratio 1500:1 |
| Viewing Angle | 89°/89°/89°/89° (Typ.)(CR≥10) |
| Display Color | 16.2M colors |
| Touch | Type Capacitive 10-point touch |
| Mohs Hardness | 7H |
| CPU | Integrated Intel® Celeron J6412 2.0GHz Quad-Core Quad-Thread Processor ,TDP 10W |
| Cooling Type | Fanless Cooling |
| Memory | 1* SODIMM slot, support single-channel 2400MHz DDR4 memory, maximum support 16GB |
| Memory | Function SSD |
| Operating System | WIN10/WIN 11 pre-installed (no activation code) |
| Dimension | 395*309.5*57.9mm |
| Material | LCD screen + glass panel + stainless steel body |
| Network Functions | 2* RTL8111H Gigabit LAN card, support Wake-on-LAN and PXE function. |
| Audio Functions | On-board ALC897 7.1+2-channel hi-fi audio controller, support MIC/Line-out. amplifier Support for audio input and output |
| Interfaces | 1× DC_IN power supply interface 1× HDMI 1×VGA 2× USB3.0,2X USB2.0 1× LAN interface 2xCOM 1× Mic (input) 1× PHONE (Output) 1× VGA |
| DC | 9-36V wide voltage |
| Wireless Network | wifi 2.4& 5G，bluetooth |
