RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals

RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals

RUGGEDMASTER catalog model: RM-SC-4B562CAD8543.

RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals combines Waterproof: IP54, Shockproof: MIL-STD-810H, Display: 5inch IPS 16:9 540×960. Additional features include CPU: MTK6761 Quad-core, Battery: 3900mAh. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.

RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals features

Product Introduction

Design and technical configuration

The RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals technical information lists the following configuration details.

Waterproof: IP54. Shockproof: MIL-STD-810H. Optional: hot-Swap battery. Operation: Android 10.

Display: 5inch IPS 16:9 540×960. Camera: Rear 8.0MP. CPU: MTK6761 Quad-core. Storage: DDR2GB+16GB.

GSM: B5/850;B8/900;B3/1800;B2/1900;. WCDMA: B1/2100;B2/1900;B5/850;B8/900 (Mass order optional B4). 4G LTE: FDD LTE B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20 TDD: B38/B39/B40/B41. Sim Card: Dual SIM card (nano size).

WiFi: 2.4/5GHz A/B/G/N/AC support WiFi roaming. Navigation: GPS+GLONASS. 2D Scanner SE4710(MOTO) Honeywell 3601: Honeywell 3603 (white light). FM/BT: Yes/BT4.2.

Sensor: 3D accelerator,E-compass,proximity sensor,Light sensor supported. Music/video: video decoding 3gp/H.265/MPEG4. Battery: 3900mAh. USB port: Type-C.

T-flash: MAX support 64GB. Products size: 165x78x23/. Accessories:: Adaptor, user manual, type-C.

Configuration and compatibility

Check the listed dimensions, power requirements and connection interfaces before selecting this model. Optional functions remain separate from the standard configuration. Where the specifications list more than one memory capacity, colour or operating system, confirm the required configuration in your enquiry. The product is presented as one model, with its technical information and photos together for comparison.

Preparing a deployment enquiry

To compare this handheld terminals configuration with your existing equipment, start with the tasks your team performs and the software it uses. Check the operating system and application requirements against the listed processor, memory and storage. For connected workflows, compare the specified communication methods and interfaces with your network and peripherals. If scanning or identification is part of the job, identify the barcode types or card standards required before choosing optional hardware. Review the source photos alongside the dimensions to assess handling, mounting and access to connections. Include these requirements with your requested quantity so the proposed configuration can be checked before supply. Listed options need confirmation; the gallery may illustrate several configurations.

RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals wholesale enquiries

Explore the product photos and the separate Specs tab for RUGGEDMASTER RM-SC-4B562CAD8543 Handheld Terminals. Browse our industrial handhelds to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
