RUGGEDMASTER HC10R7 Industrial Computers

RUGGEDMASTER HC10R7 product details

RUGGEDMASTER HC10R7 industrial computers. 10.1 Inch 4G LTE Linux Ubuntu OS Industrial Tablet PC RK3576 CPU Dual Cameras NFC 2D Barcode scanner Vehicle Wall Mount Tablet.

RUGGEDMASTER HC10R7 key features

• Operation System: Android 14.0 or Linux Ubuntu 24.04，
• CPU: Rockchips RK3576 Octa-core 2.2GHz,4 * Cortex-A72 2.2Ghz+4 * Cortex-A53 1.8Ghz;
• Display: 10.1 inch Capacitive Multi-touch IPS FHD screen 1200*1920pixels;
• Memory & Storage: 8GB ram+128GB Rom;
• Battery: 3.8V / 10000mah lithium battery,can work >=8-10 hours,optional;
• Wireless network: 802.11 a/c/b/g/n 2.4G+5Ghz Wifi, and bluetooth V5.0;
• 4G Networks: Support GSM: B5/B8/B3/B2,3G WCDMA: B1/B5/B8,
• NFC: ST21,13.56Mhz,Support ISO/IEC 14443A/B/15693/mifare protocol, is optional;
• 2D Barcode scanner: is optional;

Model NO. : HC10R7

Specifications:

1.CPU: Rockchips RK3576 Octa-core 2.2GHz,4 * Cortex-A72 2.2Ghz+4 * Cortex-A53 1.8Ghz;

2.Operation System: Android 14.0 or Linux Ubuntu 24.04，

3.Display: 10.1 inch Capacitive Multi-touch IPS FHD screen 1200*1920pixels;

4.Two Cameras: Front 5.0MP camera, Back 13.0MP Camera;

5.Memory & Storage: 8GB ram+128GB Rom;

6.Wireless network:  802.11 a/c/b/g/n 2.4G+5Ghz Wifi, and bluetooth V5.0;

7.4G Networks: Support GSM: B5/B8/B3/B2,3G WCDMA: B1/B5/B8,

4G FDD LTE: B1/B2/B3/B5/B7/B8/B20,optional;

8.Navigation: Support GPS+Glonass+Beidou+Galileo, is optional;

9.Battery: 3.8V / 10000mah lithium battery,can work >=8-10 hours,optional;

10.Speaker: Built-in 8Ω/0.8W speaker * 2 speakers;

11.I/O ports:1*DC port, 1*Type-C USB Port,1*USB2.0 Host,1*RJ45 Ethernet Port,1*TF card slot,1*Pogo Pin port (optional);

12.NFC: ST21,13.56Mhz,Support ISO/IEC 14443A/B/15693/mifare protocol, is optional;

13.2D Barcode scanner:  is optional;

14.Vehicle holder or Wall mount holder: VESA design,Optional;

15.Dimension and Weight: about 248*187*9.2mm, about 800g.

Planning a team deployment

Review the RUGGEDMASTER HC10R7 specifications alongside the applications your team needs to use. Check the listed operating system, display dimensions and available interfaces before selecting a device for your workflow. When a scanner, reader or other module is described as optional, include that requirement in your enquiry so the exact configuration can be confirmed. Product illustrations may show an optional module or an example application. Use the written specifications to identify the capabilities required for your project.

Configuration and compatibility

For a team rollout, record the exact model, the quantity needed at each location and the software used by your staff. Match the listed network information to your destination and operating environment. Check storage requirements, charging arrangements and existing peripheral connections before preparing your shortlist. Where several memory or processor configurations are listed, confirm the requested configuration with RuggedMaster. Optional accessories and example setups help illustrate a workflow; configuration requirements should be included in your purchasing enquiry.

RUGGEDMASTER HC10R7 bulk order enquiries

For wholesale quantities and bulk orders, contact RuggedMaster with the exact model, required quantities, preferred configuration and destination. Include any scanning, identification or software requirements for your application. Review the Specs tab and product illustrations when comparing models. Availability, the requested configuration and order details should be confirmed before purchase.
