RUGGEDMASTER CMX-D801 Rugged Tablets

RUGGEDMASTER CMX-D801 Rugged Tablets

RUGGEDMASTER CMX-D801 rugged tablets is listed for wholesale enquiries through RuggedMaster. Octa-core 64-bit 2 .0GHz high-performance processor, Android 13, 4GB+64GB, 8″,screen resolution1280 x 800/1920×1200 (Optional), Rechargeable polymer battery (3.8V 9000mAh), N6602-W2 2D/Honeywell N6703/N5703 2D.

Here is a basic parameter of CMX-D801 Android Industrial Tablet

Special Note : Product data is for reference only and subject to change without notice

RUGGEDMASTER CMX-D801 features and specifications

Model: CMX-D801.

CPU: Octa-core 64-bit 2 .0GHz high-performance processor.

RAM+ROM: 4GB+64GB.

System: Android 13.

WLAN: Dual-band 2.4GHz / 5GHz Support IEEE 802.11ac/a/b/g/ n/d/e/h/i/j/k/r/v protocol.

WWAN: 2G:GSM (850/900/ 1800/ 1900MHz) 3G:WCDMA (850/900/ 1900/2100MHz) 4G:FDD:B1/B3/B4/B7/B8/B12/B20 TDD:B38/B39/B40/B41.

Bluetooth: Support Bluetooth5.0+BLE,transmission distance 5-10 meters.

GNSS: Support GPS,Beidou, Glonass ,Galileo ,AGPS , built-in antenna.

Dimensions: 211.5mm×136mm×16.3mm (The thinnest).

Weight: <700g (Including battery).

Display: 8″,screen resolution1280 x 800/1920×1200 (Optional).

TP: Supports multi-touch.

Battery capacity: Rechargeable polymer battery (3.8V 9000mAh) Standby time>350 hours Working time>10 hours Charging time 2-3 hours,use standard power adapter and data cable.

Expansion Card slot: SIM x 1,SIM/TF x1 ,PSAM x2(Optional).

Communication interface: Type-C USBx1,OTG ,USBA x2 (Optional).

Speaker volume: >90db (test distance 10cm).

Audio: Speaker (mono),Microphon ,Receiver.

Keypad: Power key x1,Volume Side key x1,User set key x2.

Sensors: Gravity sensor,Gyroscope,Acceleration sensor.

Barcode Scanning: N6602-W2 2D/Honeywell N6703/N5703 2D.

1D Symbologies: UPC/EAN , Code128 , Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI , RSS,etc . Postal Codes:USPS Planet , USPS Postnet , China Post , Korea Post , Australian Postal, Japan Postal,Dutch Postal (KIX), Royal Mail, Canadian Customs ,etc …

2D Symbologies: PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,MaxiCode ,Hanxin Code,etc..

Rear camera: 13MP color camera/20MP color camera(Optional) Support auto focus,Flash,Anti-shake,Macro shooting.

Front camera: 5MP color camera.

Frequency: 865-868 MHz((EHR).

Protocol: EPC C1 GEN2 / ISO18000-6C.

Distance: 0-10m.

Frequency: Configure TCS semiconductor sensor with live identification technology.

Collection area: 11.3×12.4mm.

Resolution: 508 dpi,8-bit grayscale.

Extraction format: ISO 19794,WSQ,ANSI 378,JPEG2000.

Secure encryption: AES,DES key encryption for host communication channel.

Frequency: 13.56MHz.

Protocol: Support ISO14443A/B,15693 agreement.

Distance: 2cm-5cm.

Operating temperature: -20℃ – 55℃.

Storage temperature: -40℃ – 70℃.

Environment humidity: 5%RH–95% RH(no condensation).

Drop: 6 sides can withstand a height of 1.5 meters,falling to the marble..

Rolling test: 0.5m continuous rolling,1000 times.

Sealing: IP66.

Standard: Adapter,Data cable,Protective film,Instruction manual.

Optional: Docking station:Communication interface RJ45x1,RS232x1,USBAx2.

RUGGEDMASTER CMX-D801 bulk orders

For a RUGGEDMASTER CMX-D801 wholesale enquiry, provide the model name, intended application, order quantity and destination. Compare the listed hardware and connections with your project requirements. The complete manufacturer specifications are available in the Specs tab. Keep the model number with your purchasing records so repeat enquiries refer to the same listing.

Check the software and peripheral requirements of your project before placing an enquiry. Review the operating system, processor, memory and available ports where these are listed. For scanning equipment, check the supported barcode types and interface. For portable equipment, review the screen, battery and wireless connections. Select the relevant specifications for your workflow.

Product photographs and manufacturer feature illustrations show the equipment and its intended applications. Equipment used in demonstration scenes may be separate from the listed product. Refer to the stated package contents and specifications when confirming the configuration. Ask about any required accessories by name so the enquiry identifies the complete setup for your business.

Compare the RUGGEDMASTER CMX-D801 dimensions and operating conditions with the installation environment. For handheld devices, consider how staff will carry and use the equipment. For fixed equipment, check the mounting position, power connection and host system interface. Use the manufacturer values to make the comparison, and confirm any configuration options with your enquiry.
