NETUM W9 Barcode Scanners

NETUM W9 Barcode Scanners

NETUM W9 barcode scanners is listed for wholesale enquiries through RuggedMaster. .

Scan Performance

Light Resource: CMOS Image Sensor Processor: 32-bit High-speed CPU Decoding Speed: 200 times/second Precision: ≥5mil (0.10mm) Decode Error Rate: Less than 1/8 million Print Contrast Signal: ≥25% Scan Angle: Yaw(Skew) 55°, Pitch 55° Max Scanning Area: 600×600mm Supported 1D Symbologies: Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11 Supported 2D Symbologies: PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), Chinese Sensible Code Depth of Scan Field: Code 128 (10mil): 60mm~200mmPaper QR Code 160 bytes (10mil): 40mm-120mmPaper DM Code 100 bytes (15mil): 50mm-140mmScreen QR Code 18 bytes (10mil): 50mm-250mm

Mechanical / Electrical Parameters

Working Voltage: 5 VDC ±5% Working Current: 260mA Power Consumption: 0.33W Ultra-low power Interface Mode: USB / COM / PS/2 Triple interfaces

Environmental Specifications

Operating Temperature: 0°C~+50°C Storage Temperature: -20°C~+70°C Relative Humidity: 5% – 95% (Non-condensing) Protection Level: IP54 Dustproof & Waterproof

Customization & Certification

Language Support: 25 Global Multilingual Programmable Function: Custom Prefix/Suffix, Character Deletion, TAB/CR&LF Shortcut Setting Certifications: CE, ROHS, FCC, IP54 Certified Warranty: 24-Month Long Warranty

High-Precision & High-Speed Decoding Performance

NETUM W9 is a professional wired 2D barcode scanner designed for high-volume commercial and industrial scanning scenarios. Powered by advanced 32-bit CPU processor and high-sensitivity CMOS imaging sensor , it achieves a fast decoding speed of 200 scans per second and ultra-high scanning precision of 5mil (0.10mm) . With an ultra-low error rate of less than 1/8 million, it stably identifies ordinary printed barcodes, screen electronic barcodes, as well as blurred, damaged and poorly printed barcodes, ensuring efficient and accurate operation in high-intensity working environments.

Global Multilingual & Full Programmable Customization

Different from ordinary scanners, the W9 supports 25 global languages and provides customized PDF manuals in Spanish, German, French, Italian, Japanese and other languages, perfectly matching international enterprise business needs. It features powerful programmable functions, allowing B-end users to freely set custom prefixes and suffixes, remove redundant characters, and configure TAB, CR&LF shortcut commands. It can be perfectly embedded into various POS systems, WMS inventory software and enterprise management platforms to optimize business workflows.

Triple Universal Interfaces & Low Power Consumption

IP54 Rugged Durability & Long-Term Reliability

Built with high-strength black ABS housing and IP54 dustproof and waterproof grade , the scanner resists daily dust, splash water and accidental collision, adapting to complex factory and warehouse environments. It supports omnidirectional 55° scanning angle for flexible multi-angle operation. Backed by an industry-leading 24-month warranty , it provides reliable long-term operation and reduces after-sales maintenance costs for global business buyers.

Application Scenarios

– Retail supermarket POS checkout and mobile screen QR payment scanning – Warehouse inventory counting, logistics sorting and oversized pallet barcode identification – Healthcare facilities for patient wristband and medical medication label scanning – Library archive management, bank and telecom business barcode registration – Industrial manufacturing parts traceability and enterprise inventory system data collection

NETUM W9 features and specifications

Light Resource: CMOS Image Sensor Processor: 32-bit High-speed CPU Decoding Speed: 200 times/second Precision: ≥5mil (0.10mm) Decode Error Rate: Less than 1/8 million Print Contrast Signal: ≥25% Scan Angle: Yaw(Skew) 55°, Pitch 55° Max Scanning Area: 600×600mm Supported 1D Symbologies: Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11 Supported 2D Symbologies: PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), Chinese Sensible Code Depth of Scan Field: Code 128 (10mil): 60mm~200mmPaper QR Code 160 bytes (10mil): 40mm-120mmPaper DM Code 100 bytes (15mil): 50mm-140mmScreen QR Code 18 bytes (10mil): 50mm-250mm.

Working Voltage: 5 VDC ±5% Working Current: 260mA Power Consumption: 0.33W Ultra-low power Interface Mode: USB / COM / PS/2 Triple interfaces.

Operating Temperature: 0°C~+50°C Storage Temperature: -20°C~+70°C Relative Humidity: 5% – 95% (Non-condensing) Protection Level: IP54 Dustproof & Waterproof.

Language Support: 25 Global Multilingual Programmable Function: Custom Prefix/Suffix, Character Deletion, TAB/CR&LF Shortcut Setting Certifications: CE, ROHS, FCC, IP54 Certified Warranty: 24-Month Long Warranty.

NETUM W9 bulk orders

For a NETUM W9 wholesale enquiry, provide the model name, intended application, order quantity and destination. Compare the listed hardware and connections with your project requirements. The complete manufacturer specifications are available in the Specs tab. Keep the model number with your purchasing records so repeat enquiries refer to the same listing.

Check the software and peripheral requirements of your project before placing an enquiry. Review the operating system, processor, memory and available ports where these are listed. For scanning equipment, check the supported barcode types and interface. For portable equipment, review the screen, battery and wireless connections. Select the relevant specifications for your workflow.

Product photographs and manufacturer feature illustrations show the equipment and its intended applications. Equipment used in demonstration scenes may be separate from the listed product. Refer to the stated package contents and specifications when confirming the configuration. Ask about any required accessories by name so the enquiry identifies the complete setup for your business.

Compare the NETUM W9 dimensions and operating conditions with the installation environment. For handheld devices, consider how staff will carry and use the equipment. For fixed equipment, check the mounting position, power connection and host system interface. Use the manufacturer values to make the comparison, and confirm any configuration options with your enquiry.
