NETUM RD-2023 Barcode Scanners

NETUM RD-2023 Barcode Scanners

NETUM RD-2023 barcode scanners is listed for wholesale enquiries through RuggedMaster. Relative Humidity: 0%~95% RH (non-condensable) Ambient Light Resistance : Max 100,000Lux.

Scanning Performance Scanning Engine : CMOS Global Shutter Imager Sensor : 1280 × 1024 (1.3MP) Illumination : White LED Aiming Method : Red LED Maximum Frame Rate : 50fps Minimum Resolution : 1D≥3mil ; 2D≥4mil Contrast : ≥20% Scan Angle : Roll 360°, Pitch ±60°, Skew ±60° Field of View : Horizontal 40°, Vertical 34° Depth of Field : Code 39 (3mil) : 45mm ~ 80mm Code 39 (5mil) : 35mm ~ 100mm Data Matrix (5mil) : 45mm ~ 75mm Data Matrix (10mil) : 45mm ~ 220mm EAN13 (13mil) : 60mm ~ 400mm Supported 2D Symbologies : Data Matrix, Dot Code, QR Code, Micro QR, PDF417, Micro PDF417, Aztec, MaxiCode Supported 1D Symbologies : UPC-A, UPC-E, EAN-8, EAN-13, Code128, Code39, Code93, Code32, Code11, Codabar, Plessey, MSI, Interleaved 2 of 5, IATA 2 of 5, Matrix 2 of 5, Straight 2 of 5, Pharmacode, GS1 DataBar Series, Composite Code A/B/C

Electrical Parameters Operating Voltage : DC 5V±5% Operating Current : Max 0.8A Typical Power Consumption : 1.5W @5VDC Communication InterfaceInterface Mode : USB(HID-KBW/Virtual Serial Port), TTL-232 Industrial Interface Physical Parameters Dimension : 180 × 65 × 95 mm Weight : ≈254g Color : Black, Yellow Cable Length : 1.2m Material : Industrial ABS Operating Environment Operating Temperature : 0℃ ~ 50℃ Storage Temperature : -40℃ ~ 70℃

Relative Humidity : 0%~95% RH (non-condensable) Ambient Light Resistance : Max 100,000Lux

Professional Global Shutter Industrial DPM Scanning Performance NETUM RD-2023 is a dedicated wired industrial DPM barcode scanner for intelligent manufacturing scenarios. It adopts 1.3MP global shutter CMOS sensor with 1280×1024 high resolution and 50fps max frame rate. Equipped with white LED uniform fill light and red LED precise aiming system, it delivers ultra-clear imaging for various industrial marking codes. The upgraded industrial decoding algorithm greatly improves the recognition rate for dirty, defective, scratched and low-contrast barcodes, solving common unreadable problems in industrial on-site scanning.

Powerful DPM Special Code Decoding Ability This scanner professionally adapts to multiple industrial permanent marking methods, including laser etching, dot peen marking, chemical etching and industrial inkjet printing. It stably reads difficult codes such as metal surface laser codes, PCB hollow codes, casting dot codes, oil-stained surface codes and cylindrical etching codes. It is widely applicable for precision parts, hardware accessories, electronic components and mechanical equipment identification.

Dual Industrial Interface for Equipment System Integration RD-2023 supports dual communication methods: USB HID-KBW, USB virtual serial port and TTL-RS232 industrial interface. It can be seamlessly connected with industrial control equipment, PLC, industrial host computers and traditional POS systems, realizing stable and long-term uninterrupted data transmission. The plug-and-play design reduces deployment difficulty, matching various industrial intelligent transformation projects. Full Symbology Coverage & Secondary Development Support Compatible with almost all mainstream 1D and 2D industrial barcode symbologies, including Data Matrix, QR Code, PDF417, GS1 series codes and various industrial 2/5 codes. Built-in professional secondary development SDK, convenient for enterprise secondary development and system docking, meeting personalized customized scanning needs of different intelligent manufacturing production lines.

Stable Industrial-Grade Hardware Structure Adopts high-strength ABS industrial casing, ergonomic handheld design, durable for long-term high-frequency industrial operation. Wide temperature and humidity adaptation range, strong anti-interference ability against ambient light, stable operation in complex factory environment, ensuring long-term reliable industrial data collection work.

Application Scenarios

Manufacturing Production Line Process Traceability Accurately identify various printed and etched barcodes on production line workpieces, realize full-process product traceability and quality inspection record management. Industrial Parts & Component Barcode Collection Specially optimized for metal laser engraving codes, PCB hollow codes, casting dot peen codes and oily surface codes, solving difficult scanning problems for industrial parts marking. Industrial Equipment Maintenance Scanning Stably read worn, dirty and low-contrast equipment identification codes, assist equipment file management, regular maintenance and fault traceability in factories. On-Site Industrial Data Acquisition Suitable for harsh industrial workshop environments, support stable high-precision barcode collection to ensure accurate and consistent industrial data statistics.

NETUM RD-2023 features and specifications

Scanning Performance Scanning Engine: CMOS Global Shutter Imager Sensor : 1280 × 1024 (1.3MP) Illumination : White LED Aiming Method : Red LED Maximum Frame Rate : 50fps Minimum Resolution : 1D≥3mil ; 2D≥4mil Contrast : ≥20% Scan Angle : Roll 360°, Pitch ±60°, Skew ±60° Field of View : Horizontal 40°, Vertical 34° Depth of Field : Code 39 (3mil) : 45mm ~ 80mm Code 39 (5mil) : 35mm ~ 100mm Data Matrix (5mil) : 45mm ~ 75mm Data Matrix (10mil) : 45mm ~ 220mm EAN13 (13mil) : 60mm ~ 400mm Supported 2D Symbologies : Data Matrix, Dot Code, QR Code, Micro QR, PDF417, Micro PDF417, Aztec, MaxiCode Supported 1D Symbologies : UPC-A, UPC-E, EAN-8, EAN-13, Code128, Code39, Code93, Code32, Code11, Codabar, Plessey, MSI, Interleaved 2 of 5, IATA 2 of 5, Matrix 2 of 5, Straight 2 of 5, Pharmacode, GS1 DataBar Series, Composite Code A/B/C.

Electrical Parameters Operating Voltage: DC 5V±5% Operating Current : Max 0.8A Typical Power Consumption : 1.5W @5VDC Communication InterfaceInterface Mode : USB(HID-KBW/Virtual Serial Port), TTL-232 Industrial Interface Physical Parameters Dimension : 180 × 65 × 95 mm Weight : ≈254g Color : Black, Yellow Cable Length : 1.2m Material : Industrial ABS Operating Environment Operating Temperature : 0℃ ~ 50℃ Storage Temperature : -40℃ ~ 70℃.

Relative Humidity: 0%~95% RH (non-condensable) Ambient Light Resistance : Max 100,000Lux.

NETUM RD-2023 bulk orders

For a NETUM RD-2023 wholesale enquiry, provide the model name, intended application, order quantity and destination. Compare the listed hardware and connections with your project requirements. The complete manufacturer specifications are available in the Specs tab. Keep the model number with your purchasing records so repeat enquiries refer to the same listing.

Check the software and peripheral requirements of your project before placing an enquiry. Review the operating system, processor, memory and available ports where these are listed. For scanning equipment, check the supported barcode types and interface. For portable equipment, review the screen, battery and wireless connections. Select the relevant specifications for your workflow.

Product photographs and manufacturer feature illustrations show the equipment and its intended applications. Equipment used in demonstration scenes may be separate from the listed product. Refer to the stated package contents and specifications when confirming the configuration. Ask about any required accessories by name so the enquiry identifies the complete setup for your business.

Compare the NETUM RD-2023 dimensions and operating conditions with the installation environment. For handheld devices, consider how staff will carry and use the equipment. For fixed equipment, check the mounting position, power connection and host system interface. Use the manufacturer values to make the comparison, and confirm any configuration options with your enquiry.
