NETUM NT-212F Barcode Scanner Modules

NETUM NT-212F Barcode Scanner Modules

NETUM NT-212F barcode scanner modules is listed for wholesale enquiries through RuggedMaster. EAN-13 (13mil): 35mm – 420mm.

Optical & Scanning Performance

Image Sensor : 1280×800 CMOS (1.28MP High Resolution) Illumination Light : White LED Aiming Light : Red LED Minimum Resolution : ≥5mil Print Contrast Ratio : ≥25% Field of View : Horizontal 42°, Vertical 28° Scan Angle : Rotation 360°, Tilt ±55°, Skew ±55° Ambient Light Immunity : 0~100,000 LUX

Typical Depth of Field

EAN-13 (13mil) : 35mm – 420mm

Supported 1D Symbologies

EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleaved 2 of 5 and more mainstream 1D barcodes

Supported 2D Symbologies

QR Code, Data Matrix, PDF417 and mainstream 2D barcode formats

Interface & Electrical Parameters

Communication Interface : TTL-232, USB (HID-KBW, Virtual COM Port) Operating Voltage : DC 3.3V Operating Current : 180mA (Peak) Standby Current : 30mA

Physical & Environmental Parameters

Dimension : 10.4mm(L) × 21.8mm(W) × 11.9mm(H) Operating Temperature : -20℃ ~ +50℃ Storage Temperature : -40℃ ~ +70℃ Operating Humidity : 5% ~ 95% (Non-condensing) Durability Features : ESD Protection, Dust Resistant Sealed Design

1.28MP High-Resolution Embedded Scanning Module NETUM NT-212F is a high-performance compact embedded 2D barcode scanner module designed for industrial and commercial embedded scenarios. Equipped with advanced 1280×800 1.28-megapixel CMOS sensor, it captures ultra-high-definition barcode images, supports 5mil high-precision decoding, and stably identifies dense, tiny and low-quality printed barcodes, meeting strict industrial identification standards.

Full-Coverage 1D/2D Barcode Decoding Capability This module supports all mainstream commercial and industrial barcode symbologies, including 2D QR Code, Data Matrix, PDF417 and 1D EAN, UPC, Code 39, Code 128 series. It can smoothly decode both paper printed barcodes and screen electronic codes, fully adapting to retail settlement, logistics traceability and industrial production detection scenarios. Dual Interface Flexible Industrial Integration NT-212F is equipped with TTL-232 serial port and USB dual communication modes, compatible with USB HID-KBW keyboard output and Virtual COM data transmission. The dual-interface design adapts to various industrial control systems and portable device mainboards, realizing fast plug-and-play integration and greatly reducing secondary development difficulty for B-end manufacturers. Mini Compact Size for Multi-Scenario Embedding Featuring ultra-small body dimension of 10.4×21.8×11.9mm, the module has an ultra-compact and lightweight structure. It can be easily embedded into PDA, industrial tablets and various slim intelligent devices with limited internal space, becoming the preferred core scanning component for portable and mini intelligent equipment.

Industrial-Grade Stable Environmental Adaptability Built-in ESD protection and fully sealed dustproof structure, paired with white LED uniform fill light and red precise aiming light. It supports ultra-wide operating temperature range of -20℃ to +50℃ and 0~100000LUX strong light resistance, maintaining long-term stable and efficient decoding performance in complex indoor, outdoor and industrial workshop environments.

Application Scenarios

PDA & Portable Smart Device Integration

Perfect for industrial handheld PDA, logistics portable terminals and intelligent tablet equipment, providing stable high-precision barcode scanning functions for mobile data collection.

Self-Service Terminal Embedded System

Suitable for ticket vending machines, self-checkout terminals, inquiry equipment and unattended kiosks, realizing automatic and efficient barcode identification.

Lightweight Intelligent Equipment Matching

Ideal for various slim intelligent devices and mini automated scanning equipment, solving space limitation problems of embedded scanning modules.

Industrial Embedded Data Acquisition

Widely used in factory fixed-point scanning stations, production traceability, batch barcode identification and industrial automated data collection projects.

NETUM NT-212F features and specifications

Image Sensor: 1280×800 CMOS (1.28MP High Resolution) Illumination Light : White LED Aiming Light : Red LED Minimum Resolution : ≥5mil Print Contrast Ratio : ≥25% Field of View : Horizontal 42°, Vertical 28° Scan Angle : Rotation 360°, Tilt ±55°, Skew ±55° Ambient Light Immunity : 0~100,000 LUX.

EAN-13 (13mil): 35mm – 420mm.

Communication Interface: TTL-232, USB (HID-KBW, Virtual COM Port) Operating Voltage : DC 3.3V Operating Current : 180mA (Peak) Standby Current : 30mA.

Dimension: 10.4mm(L) × 21.8mm(W) × 11.9mm(H) Operating Temperature : -20℃ ~ +50℃ Storage Temperature : -40℃ ~ +70℃ Operating Humidity : 5% ~ 95% (Non-condensing) Durability Features : ESD Protection, Dust Resistant Sealed Design.

NETUM NT-212F bulk orders

For a NETUM NT-212F wholesale enquiry, provide the model name, intended application, order quantity and destination. Compare the listed hardware and connections with your project requirements. The complete manufacturer specifications are available in the Specs tab. Keep the model number with your purchasing records so repeat enquiries refer to the same listing.

Check the software and peripheral requirements of your project before placing an enquiry. Review the operating system, processor, memory and available ports where these are listed. For scanning equipment, check the supported barcode types and interface. For portable equipment, review the screen, battery and wireless connections. Select the relevant specifications for your workflow.

Product photographs and manufacturer feature illustrations show the equipment and its intended applications. Equipment used in demonstration scenes may be separate from the listed product. Refer to the stated package contents and specifications when confirming the configuration. Ask about any required accessories by name so the enquiry identifies the complete setup for your business.

Compare the NETUM NT-212F dimensions and operating conditions with the installation environment. For handheld devices, consider how staff will carry and use the equipment. For fixed equipment, check the mounting position, power connection and host system interface. Use the manufacturer values to make the comparison, and confirm any configuration options with your enquiry.
