NETUM DS-8100 Barcode Scanners

NETUM DS-8100 Barcode Scanners

NETUM DS-8100 barcode scanners is listed for wholesale enquiries through RuggedMaster. 1.Buzzer 2.LED Indicator Light 3.Vibration Scan Mode (Hand‑held): 1.Trigger Mode 2.Continuous Mode 3.Auto Sense Mode Charging Interface: USB(B)/USB(A), IP54 Shock Resistance: 1 Meter High Free Fall Certificates: CE, FCC, ROHS.

Optical property

Imaging Sensor: CMOS (Global Exposure) Resolution: 640×480, Global Exposure Illumination: Aimer Red color LED, Illumination White color LED Scan Mode: Image Scanning Precision: 1D ≥4mil，2D ≥6.8mil Print Contrast: ≥20%

Operating Characteristic

Operating Environment: ‑10℃‑50℃ Storage Environment: ‑20℃‑70℃ Operating Humidity: 5%‑95%(No Condensation) Ambient Illumination: 60000 lx

Electrical Specification

Working Voltage: DC5.0V±5% Maximum Current: 395mA Battery Capacity: 2000 MAH Charging Time: 5‑7 hours

Transmission Performance

Transmission Mode: 2.4G Wireless / Bluetooth Transmission Distance: 2.4G In Open Visual Distance ≤60 Meters；Bluetooth In Open Visual Distance ≤10 Meters

Decoding Capability

Scan Angle: 34°×V30° H(Nominal) Depth of Field: Code 128 60mm‑200mm(10mil) QR Code 160 bytes(paper) 50mm‑140mm(10mil) DM Code 100 bytes(paper) 50mm‑120mm(10mil) QR Code 18 bytes(screen) 50mm‑250mm(10mil) Decoding: 2D: PDF‑417,QR Code,QR1/2,Micro QR,Data Matrix,ECC200,ECC000,050,080,100,140,Chinese Sensible Code etc. 1D: Code128,UCC/EAN‑128,AIM128,EAN‑8,EAN‑13,ISBN/ISSN,UPC‑E,UPC‑A,Interleaved 2 of 5,ITF‑6,ITF‑4,Matrix 2 of 5,Industrial 25,Standard 25,Code39,Codabar Code93,Code11 etc.

RFID parameter

Carrier Frequency: 13.56 MHz (RFID HF) Read/Write Speed: 26 kbps (ISO 15693),106kbps (ISO 14443) Antenna: Integration,25mm×4mm,Balance Supported Protocol: ISO15693,ISO/IEC 14443 A and B; Mifare, Sony FeliCa, Conform to EPC GEN2 13.56MHz Maximum RFID reading range: 0.4"‑2" (10‑30 mm)

Others

Prompting Mode: 1.Buzzer 2.LED Indicator Light 3.Vibration Scan Mode (Hand‑held): 1.Trigger Mode 2.Continuous Mode 3.Auto Sense Mode Charging Interface: USB(B)/USB(A)

Physical Property

Dimension L W H: 205 73 110mm Cable: 1.5m Color: Blue/White

Safety Code

IP Rating: IP54 Shock Resistance: 1 Meter High Free Fall Certificates: CE, FCC, ROHS

NETUM DS8100 Hybrid RFID Imager is the future of the data capture industry. Under programmatic control, the reader seamlessly supports the widest variety of HF RFID tags and bar code labels, as well as standard and most proprietary card formats; suitable for hospitality, retail, and logistic industry settings via Bluetooth low-energy connection. Compatible with Windows, Mac OS, iOS and Android. the DS8100 makes RFID and bar code reading simple.

With the DS8100 Series, you can give shoppers the checkout experience they expect — short lines, a speedy transaction and attentive service. A one-of-a-kind hybrid design provides maximum flexibility, offering both handheld and hands-free scanning. You get NETUM’s industry-leading scanning technology, seamless switching between modes and superior ease of use, along with a wide range of innovative features that boost productivity. An RFID model combines a barcode scanner and RFID reader to extend the benefits of RFID to your point of sale.

Application Scenarios

Membership & ID Card Identification: Membership card, employee ID card, visitor badge and paper ticket recognition. HF RFID Asset Management: High‑frequency RFID asset tag reading, equipment inventory and property tracking. Retail & Anti‑Counterfeiting Collection: Store on‑site data acquisition, commodity anti‑counterfeiting verification and customer identity checking. Event & Ticketing System: Ticket verification, access control data collection for exhibitions and activities. Government & Public Service: On‑site information collection for identity documents and smart card processing.

NETUM DS-8100 features and specifications

Imaging Sensor: CMOS (Global Exposure) Resolution: 640×480, Global Exposure Illumination: Aimer Red color LED, Illumination White color LED Scan Mode: Image Scanning Precision: 1D ≥4mil，2D ≥6.8mil Print Contrast: ≥20%.

Operating Environment: ‑10℃‑50℃ Storage Environment: ‑20℃‑70℃ Operating Humidity: 5%‑95%(No Condensation) Ambient Illumination: 60000 lx.

Working Voltage: DC5.0V±5% Maximum Current: 395mA Battery Capacity: 2000 MAH Charging Time: 5‑7 hours.

Transmission Mode: 2.4G Wireless / Bluetooth Transmission Distance: 2.4G In Open Visual Distance ≤60 Meters；Bluetooth In Open Visual Distance ≤10 Meters.

Scan Angle: 34°×V30° H(Nominal) Depth of Field: Code 128 60mm‑200mm(10mil) QR Code 160 bytes(paper) 50mm‑140mm(10mil) DM Code 100 bytes(paper) 50mm‑120mm(10mil) QR Code 18 bytes(screen) 50mm‑250mm(10mil) Decoding: 2D: PDF‑417,QR Code,QR1/2,Micro QR,Data Matrix,ECC200,ECC000,050,080,100,140,Chinese Sensible Code etc. 1D: Code128,UCC/EAN‑128,AIM128,EAN‑8,EAN‑13,ISBN/ISSN,UPC‑E,UPC‑A,Interleaved 2 of 5,ITF‑6,ITF‑4,Matrix 2 of 5,Industrial 25,Standard 25,Code39,Codabar Code93,Code11 etc..

Carrier Frequency: 13.56 MHz (RFID HF) Read/Write Speed: 26 kbps (ISO 15693),106kbps (ISO 14443) Antenna: Integration,25mm×4mm,Balance Supported Protocol: ISO15693,ISO/IEC 14443 A and B; Mifare, Sony FeliCa, Conform to EPC GEN2 13.56MHz Maximum RFID reading range: 0.4"‑2" (10‑30 mm).

Prompting Mode: 1.Buzzer 2.LED Indicator Light 3.Vibration Scan Mode (Hand‑held): 1.Trigger Mode 2.Continuous Mode 3.Auto Sense Mode Charging Interface: USB(B)/USB(A).

Dimension L W H: 205 73 110mm Cable: 1.5m Color: Blue/White.

IP Rating: IP54 Shock Resistance: 1 Meter High Free Fall Certificates: CE, FCC, ROHS.

NETUM DS-8100 bulk orders

For a NETUM DS-8100 wholesale enquiry, provide the model name, intended application, order quantity and destination. Compare the listed hardware and connections with your project requirements. The complete manufacturer specifications are available in the Specs tab. Keep the model number with your purchasing records so repeat enquiries refer to the same listing.

Check the software and peripheral requirements of your project before placing an enquiry. Review the operating system, processor, memory and available ports where these are listed. For scanning equipment, check the supported barcode types and interface. For portable equipment, review the screen, battery and wireless connections. Select the relevant specifications for your workflow.

Product photographs and manufacturer feature illustrations show the equipment and its intended applications. Equipment used in demonstration scenes may be separate from the listed product. Refer to the stated package contents and specifications when confirming the configuration. Ask about any required accessories by name so the enquiry identifies the complete setup for your business.

Compare the NETUM DS-8100 dimensions and operating conditions with the installation environment. For handheld devices, consider how staff will carry and use the equipment. For fixed equipment, check the mounting position, power connection and host system interface. Use the manufacturer values to make the comparison, and confirm any configuration options with your enquiry.
