JEPOWER HT518-U1 Mobile Computers
CPU: MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz, Operating System: Android 12.0, Memory: 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional), Display: 5.5-inch, 720×1440 HD, Touchscreen: Industrial capacitive, multi-touch, glove / wet-hand operation, Wi-Fi: IEEE 802.11 a/b/g/n, dual band 2.4GHz + 5GHz, Bluetooth: Bluetooth 4.0 BLE, GPS: GPS / AGPS / GLONASS / BeiDou
JEPOWER HT518-U1 combines CPU: MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz, Operating System: Android 12.0, Memory: 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional). Additional features include Display: 5.5-inch, 720×1440 HD, Touchscreen: Industrial capacitive, multi-touch, glove / wet-hand operation, Wi-Fi: IEEE 802.11 a/b/g/n, dual band 2.4GHz + 5GHz. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
CPU: MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz
Operating System: Android 12.0
Memory: 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional)
Display: 5.5-inch, 720×1440 HD
SEND US A MESSAGE
Just Email Us :
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
CONTACT INFORMATION
Address: Room 1303A,Building A,127 Chenshe Yishu Chanyeyuan,Minzhi Street, LongHua District,Shenzhen 518109
Reply Within 24hours for almost message!
Description
JEPOWER HT518-U1 Mobile Computers
JEPOWER HT518-U1 combines CPU: MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz, Operating System: Android 12.0, Memory: 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional). Additional features include Display: 5.5-inch, 720×1440 HD, Touchscreen: Industrial capacitive, multi-touch, glove / wet-hand operation, Wi-Fi: IEEE 802.11 a/b/g/n, dual band 2.4GHz + 5GHz. The product photos show the appearance and connection details. Review the full specifications below to compare the available configuration for your application. Contact RUGGEDMASTER with the quantity and destination for a wholesale enquiry.
JEPOWER HT518-U1 features
HT518-U1 is a 5.5-inch Android 12 multi-functional handheld PDA terminal with optional palm recognition, designed for warehouse management, logistics, retail inventory and field service. Powered by an octa-core MT6762 processor with full 4G LTE, dual SIM dual standby and IP66 industrial protection, it delivers fast barcode scanning and reliable data collection in demanding environments. Optional modules including palm recognition, NFC, fingerprint, temperature measurement and high-precision RTK positioning make it a flexible all-in-one mobile computer for enterprise use.
Specifications
Optional Modules
Applications
FAQ
Design and technical configuration
The JEPOWER HT518-U1 technical information lists the following configuration details.
Product Type: Multi-functional Handheld Terminal / PDA / Mobile Computer. CPU: MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz. Operating System: Android 12.0. Memory: 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional).
Expandable Storage: Up to 256GB MicroSD (TF) card. Display: 5.5-inch, 720×1440 HD. Touchscreen: Industrial capacitive, multi-touch, glove / wet-hand operation. Rear Camera: 13MP with autofocus and flash.
Mobile Communication: 4G-LTE / 3G / 2G; GSM B2/B3/B5/B8; WCDMA B1/B5/B8; TDD-LTE B38/B39/B40/B41; FDD-LTE B1/B2/B3/B5/B7/B8/B20/B28a&b. Wi-Fi: IEEE 802.11 a/b/g/n, dual band 2.4GHz + 5GHz. Bluetooth: Bluetooth 4.0 BLE. GPS: GPS / AGPS / GLONASS / BeiDou.
Battery: 3.8V 4700mAh removable lithium battery. Notification: Vibration / tri-color LED breathing light / audio. Sensors: Distance, light, gravity, magnetic, gyroscope (built-in vibration motor). Audio: Built-in earpiece, speaker and microphone.
Keys: 5 physical keys: 2 side scan keys, 1 side power key, 2 side volume keys; 3 touch keys: Back / Home / Recent. Card Slot: 3-in-2 card tray, dual SIM dual standby (Nano SIM + Nano SIM, or Nano SIM + TF). Interface: Waterproof USB Type-C, USB 2.0 with OTG. Dimensions: 156mm × 76mm × 23mm.
Weight: 280g (including battery and scan module). Packing Size: Single inner box: 19cm × 11cm × 9cm; gross weight approx. 500g. Working Temperature: -20°C ~ 60°C. Storage Temperature: -40°C ~ 70°C.
JEPOWER HT518-U1 wholesale enquiries
Explore the product photos and the separate Specs tab for JEPOWER HT518-U1. Browse our mobile computers to compare related models, or send a wholesale enquiry with your quantity, destination and preferred configuration. RUGGEDMASTER can confirm supply and package details.
JEPOWER HT518-U1 specifications
| JEPOWER HT518-U1 technical specifications | |
|---|---|
| Model | HT518-U1 |
| Product Type | Multi-functional Handheld Terminal / PDA / Mobile Computer |
| CPU | MediaTek MT6762, octa-core Cortex-A53, up to 2.0GHz |
| Operating System | Android 12.0 |
| Memory | 3GB RAM + 32GB ROM (standard); 6GB + 128GB (optional) |
| Expandable Storage | Up to 256GB MicroSD (TF) card |
| Display | 5.5-inch, 720×1440 HD |
| Touchscreen | Industrial capacitive, multi-touch, glove / wet-hand operation |
| Rear Camera | 13MP with autofocus and flash |
| Mobile Communication | 4G-LTE / 3G / 2G; GSM B2/B3/B5/B8; WCDMA B1/B5/B8; TDD-LTE B38/B39/B40/B41; FDD-LTE B1/B2/B3/B5/B7/B8/B20/B28a&b |
| Wi-Fi | IEEE 802.11 a/b/g/n, dual band 2.4GHz + 5GHz |
| Bluetooth | Bluetooth 4.0 BLE |
| GPS | GPS / AGPS / GLONASS / BeiDou |
| Battery | 3.8V 4700mAh removable lithium battery |
| Notification | Vibration / tri-color LED breathing light / audio |
| Sensors | Distance, light, gravity, magnetic, gyroscope (built-in vibration motor) |
| Audio | Built-in earpiece, speaker and microphone |
| Keys | 5 physical keys: 2 side scan keys, 1 side power key, 2 side volume keys; 3 touch keys: Back / Home / Recent |
| Card Slot | 3-in-2 card tray, dual SIM dual standby (Nano SIM + Nano SIM, or Nano SIM + TF) |
| Interface | Waterproof USB Type-C, USB 2.0 with OTG |
| Dimensions | 156mm × 76mm × 23mm |
| Weight | 280g (including battery and scan module) |
| Packing Size | Single inner box: 19cm × 11cm × 9cm; gross weight approx. 500g |
| Working Temperature | -20°C ~ 60°C |
| Storage Temperature | -40°C ~ 70°C |
| Humidity | 0 ~ 95% |
| Protection | IP66; withstands 1.5m drops onto concrete on all six sides |
| Standard Accessories | Power adapter ×1, USB Type-C cable ×1, battery ×1, hand strap ×1 |
| Barcode Scanning | Zebra 4710, Honeywell HS7, Newland N1 or self-developed 2D scan engine; supports mainstream 1D/2D barcodes |
| Front Camera | 5MP, autofocus |
| NFC | 13.56MHz; ISO14443A/B, ISO15693; M1 cards (S50, S70), CPU cards, NFC tags |
| Fingerprint | Public-security certified / civilian module; 256×360 effective pixels, 508DPI |
| Human Temperature Measurement | Single-point module; distance 0-5cm; accuracy ±0.3°C; range 23-46°C |
| Infrared Thermal Imaging | Temperature matrix; 25FPS; industrial accuracy ±2°C or ±2%; range -20°C550°C (auto two-level -20150°C / 100~550°C); distance 0.5-2.5m |
| High-precision RTK Positioning | BDS+GPS+GLONASS; dual-frequency multi-constellation RTK (L1+L2), HAC26A four-wall spiral antenna; tracking sensitivity -163dBm, acquisition -147dBm; for smart city, precision agriculture, surveying & mapping |
| ETC Module | High-speed ETC non-contact recognition, compatible with national ETC settlement system, OBU recognition and active fee deduction |
| Palm Recognition | Biometric palm recognition; comparison modes 1:1 and 1:N; library capacity up to 160,000 palms; FAR ≤0.0001%, FRR ≤0.01%; recognition time <500ms; recognition distance 5-15cm; applicable angle: front & rear tilt +20°, horizontal rotation +20° |
