HiDON HR14i5 Rugged Laptops

HiDON HR14i5 product details

HiDON HR14i5 rugged laptops. HiDON 14 inch Touch Screen 16GB+256GB Wifi6 Intel Core I5-1135G7 Rugged Laptop Support Fingerprint Scanner Rugged Computer.

HiDON HR14i5 key features

• Operation System: trial-version Windows 11 pro, original Windows11 Pro is optional;
• CPU: Intel® 11th Generation KBL-R Intel® Core™ i5-1135G7 2.4G-4.2GHZ or i5-1235U Turbo 4.4Ghz; GPU: Intel Iris Xe Graphics;
• Display & Touch Screen: 14 inch FHD 1920*1080pixels LCD Monitor，brightness: 700cd/m2;
• Memory & Storage: 16GB ram (8GB ram is optional) + 256GB SSD; 512GB or 1TB=1024GB SSD is optional;
• Battery: Built-in 7.4V/1750mAh Lithium Battery+ hot-swap 7.4V/6300mah battery,
• Wireless Network: Intel AX200:support wifi6: 802.11 a/b/d/e/g/h/i/k/n/r/u/v/w/ac/ax and Blutooth 5.1;
• 4G Network (optional): 4G LTE:Quectel EC25-AU, Frequency: FDD LTE Bands: B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD: B40, WCDMA: B1/B2/B5/B8, GSM: B2/B3/B5/B8, is optional;
• Fingerprint scanner: Built-in Fingerprint Scanner:SA-FC01A04-513-A0;

Model NO. : HR14i5

Specifications:

1.CPU: Intel® 11th Generation  KBL-R Intel® Core™ i5-1135G7 2.4G-4.2GHZ or i5-1235U Turbo 4.4Ghz; GPU: Intel Iris Xe Graphics;

2.Operation System: trial-version Windows 11 pro, original Windows11 Pro is optional;

3.Display & Touch Screen: 14 inch FHD 1920*1080pixels LCD Monitor，brightness: 700cd/m2;

4.Front Camera: Front 2.0M camera;

5.Memory & Storage: 16GB ram (8GB ram is optional) + 256GB SSD; 512GB or 1TB=1024GB SSD is optional;

6. Wireless Network:  Intel AX200:support wifi6: 802.11 a/b/d/e/g/h/i/k/n/r/u/v/w/ac/ax and Blutooth 5.1;

7.Battery: Built-in 7.4V/1750mAh Lithium Battery+ hot-swap 7.4V/6300mah battery,

8.I/O Ports:2*RJ45 10/100/1000M Ethernet Port,1*DB9 (RS232 or RS485) Serial port, 3*USB3.0,1*USB2.0 Host,1*DC port(19V/3.42A), 1*TF Card Slot, 1*HDM-I 1.4a Port, 1*earphone jack, 1*Sim Card Slot,1*5-pin POGO-Pin port;

9.Rugged Durability: Waterproof and dustproof rate:IP65; Ruggedness: comply with 0.8Meter dropproof.

10.4G Network (optional): 4G LTE:Quectel EC25-AU, Frequency: FDD LTE Bands: B1/B2/B3/B4/B5/B7/B8/B28, LTE TDD: B40, WCDMA: B1/B2/B5/B8, GSM: B2/B3/B5/B8, is optional;

11.GPS:U-blox NEO-7,Support GLONASS,QZSS,GPS, Optional;

12.Fingerprint scanner: Built-in Fingerprint Scanner:SA-FC01A04-513-A0;

13.Dimention: 356*269*37mm.

Pictures:

Planning a team deployment

Review the HiDON HR14i5 specifications alongside the applications your team needs to use. Check the listed operating system, display dimensions and available interfaces before selecting a device for your workflow. When a scanner, reader or other module is described as optional, include that requirement in your enquiry so the exact configuration can be confirmed. Product illustrations may show an optional module or an example application. Use the written specifications to identify the capabilities required for your project.

Configuration and compatibility

For a team rollout, record the exact model, the quantity needed at each location and the software used by your staff. Match the listed network information to your destination and operating environment. Check storage requirements, charging arrangements and existing peripheral connections before preparing your shortlist. Where several memory or processor configurations are listed, confirm the requested configuration with RuggedMaster. Optional accessories and example setups help illustrate a workflow; configuration requirements should be included in your purchasing enquiry.

HiDON HR14i5 bulk order enquiries

For wholesale quantities and bulk orders, contact RuggedMaster with the exact model, required quantities, preferred configuration and destination. Include any scanning, identification or software requirements for your application. Review the Specs tab and product illustrations when comparing models. Availability, the requested configuration and order details should be confirmed before purchase.
